RW-0512S

RW-0512S is listed in the DC DC Converters range at ChipApex. The manufacturer field lists Recom Power. Its product description is DC DC CONVERTER 12V 3W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for RW-0512S

• Description：DC DC CONVERTER 12V 3W
• Series：ECONOLINE RW-S (3W)
• Mfr：Recom Power
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：4.5V
• Voltage - Input (Max)：9V
• Voltage - Output 1：12V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Current - Output (Max)：250mA
• Power (Watts)：3 W
• Voltage - Isolation：1 kV
• Applications：ITE (Commercial)
• Features：SCP
• Operating Temperature：-40°C ~ 80°C
• Efficiency：72%
• Mounting Type：Through Hole
• Package / Case：24-DIP Module, 8 Leads
• Size / Dimension：1.27" L x 0.58" W x 0.28" H (32.3mm x 14.7mm x 7.0mm)

DC DC Converters datasheet and documents for RW-0512S
