S-1222D50-E6T1U

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Overview

The S-1222D50-E6T1U is a positive fixed linear voltage regulator manufactured by ABLIC Inc. It operates with an input voltage range up to 28 V and provides a fixed output voltage of 5.0 V. The device supports a maximum output current of 200 mA. It is housed in a compact HSOP-6 surface-mount package. The component is designed for efficient power management in battery-powered applications, offering stable regulation under varying load conditions.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Feature Summary

• Supports high input voltage up to 28 V
• Provides fixed 5.0 V output at 200 mA
• Compact HSOP-6 surface-mount packaging

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Applications

• Battery-powered portable devices
• General-purpose power supply circuits
• Embedded system voltage regulation

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Procurement Notes

Verify the specific datasheet revision and ordering suffixes directly with ABLIC or authorized distributors. Confirm RoHS compliance status and lead times for the HSOP-6 package. Ensure the selected variant matches the required thermal performance and operating temperature range for your specific application environment.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Selection Notes

Select this regulator when a 5 V output is required from a higher voltage source up to 28 V. The 200 mA current capability suits moderate load applications. Consider the HSOP-6 package for space-constrained PCB designs. Verify that the input voltage remains within the specified limits to ensure proper dropout voltage and regulation stability.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Part Context

This component belongs to the S-1222 series of low-dropout regulators from ABLIC. The series is characterized by high withstand voltage capabilities and low current consumption. These regulators are commonly used in consumer electronics and industrial equipment where reliable voltage conversion from higher bus voltages is necessary.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Replacement Considerations

Check for direct pin-compatible alternatives within the S-1222 series or other ABLIC LDOs with similar 28 V input and 5 V output specifications. Ensure replacement parts match the 200 mA output current and HSOP-6 package dimensions.
