S-13A1H17-E6T1U3

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Overview

The S-13A1H17-E6T1U3 is a fixed linear voltage regulator from ABLIC Inc. providing a stable 1.7V output with a maximum current of 1A. It features an ultra-low dropout voltage of 0.15V at 300mA and operates within a supply voltage range up to 5.5V. The device includes built-in protection functions such as inrush current limiting, overcurrent protection, and thermal shutdown. It consumes a typical quiescent current of 1µA and offers high ripple rejection of 60dB at 1kHz. The component is housed in a compact 6-HSOP surface-mount package and supports operation across a temperature range of -40°C to +85°C.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Feature Summary

• Ultra-low dropout performance ensures efficient power delivery under varying load conditions.
• Integrated protection mechanisms include inrush current limiting, overcurrent protection, and thermal shutdown for enhanced system reliability.
• High ripple rejection capability maintains stable output voltage against input noise.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Applications

• Low voltage power management systems
• Battery-powered portable devices
• Embedded circuit regulation

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Procurement Notes

Verify the specific part number S-13A1H17-E6T1U3 against official ABLIC documentation to confirm technical specifications and RoHS compliance status. Ensure that the procurement channel provides authentic components with traceable manufacturing data. Cross-reference the datasheet for accurate packaging details and operational limits before finalizing orders.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Selection Notes

Select this regulator when a precise 1.7V output is required with minimal voltage drop under moderate loads. Consider its low quiescent current for battery efficiency and integrated protections for robust operation in sensitive electronic applications requiring stable voltage regulation.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Part Context

This component belongs to the S-13A1 series of CMOS LDO regulators manufactured by ABLIC Inc. The series is designed for power management ICs offering high precision and low power consumption. The S-13A1H17 variant specifically targets applications needing a fixed 1.7V rail with high current capability in a small footprint.

Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Replacement Considerations

Public confirmed substitute part numbers are not available in the provided source material. Verify compatibility with existing circuit designs before considering alternative components from other manufacturers.
