S1613E-2.0480(T)

Oscillators Overview

The S1613E-2.0480(T) is a standard clock oscillator manufactured by Diodes Incorporated, operating at a fixed frequency of 2.048 MHz. It utilizes LVCMOS and LVTTL output logic levels and supports a 3.3V enable/disable control function for power management. The component is housed in a compact 4-SMD, no-lead surface-mount package designed for automated assembly processes. This oscillator provides stable timing signals suitable for digital circuits requiring precise clock synchronization.

Oscillators Feature Summary

• Supports LVCMOS and LVTTL output logic standards
• Features 3.3V enable and disable control functionality
• Utilizes a compact 4-SMD no-lead surface mount package

Oscillators Applications

• T1/E1 and T3/E3 linecards
• Serial Attached SCSI (SAS) systems
• Server and storage platforms

Oscillators Procurement Notes

Verify the specific part number against official Diodes Incorporated documentation to confirm current availability status. Note that Product Change Notifications may indicate discontinuation or lifecycle changes. Ensure compatibility with required voltage levels and package dimensions before integration into design specifications.

Oscillators Selection Notes

Select this component when a 2.048 MHz clock source with LVCMOS/LVTTL outputs is required. Consider the 4-SMD no-lead package for space-constrained designs. Verify that the 3.3V enable/disable feature aligns with system power sequencing requirements and thermal constraints during operation.

Oscillators Part Context

This oscillator belongs to the S1613E series of standard clock oscillators from Diodes Incorporated. The series offers various frequencies and packages. The S1613E-2.0480(T) specifically targets applications needing a 2.048 MHz reference signal with standard logic outputs and low-profile packaging for modern PCB layouts.

Oscillators Replacement Considerations

Check for direct substitutes within the S1613E family offering identical 2.048 MHz frequency and 4-SMD package. Verify pinout compatibility and electrical characteristics such as load capacitance and drive strength before substituting with other manufacturers' components.
