S29AL008J55BFIR20

$1.36

Description：IC FLASH 8MBIT PARALLEL 48FBGA
Series：AL-J
Mfr：Cypress Semiconductor Corp
Package：Tray

SKU:e087136002cd Category: Memory IC Brand: Cypress Semiconductor Corp

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

S29AL008J55BFIR20 is listed in the Memory IC range at ChipApex. The manufacturer field lists Cypress Semiconductor Corp. Its product description is IC FLASH 8MBIT PARALLEL 48FBGA. Review the specifications below when checking this part for your BOM.

Memory IC specifications for S29AL008J55BFIR20

Description：IC FLASH 8MBIT PARALLEL 48FBGA
Series：AL-J
Mfr：Cypress Semiconductor Corp
Package：Tray
Memory Type：Non-Volatile
Memory Format：FLASH
Technology：FLASH - NOR
Memory Size：8Mbit
Memory Organization：1M x 8, 512K x 16
Memory Interface：Parallel
Clock Frequency：-
Write Cycle Time - Word, Page：55ns
Voltage - Supply：3V ~ 3.6V
Operating Temperature：-40°C ~ 85°C (TA)
Mounting Type：Surface Mount
Package / Case：48-VFBGA
Supplier Device Package：48-FBGA (8.15x6.15)
Access Time：55 ns
Grade：-
Qualification：-

Memory IC datasheet and documents for S29AL008J55BFIR20

S29AL008J55BFIR20

Memory IC Overview

The S29AL008J55BFIR20 is an 8-Mbit (1M x 8-Bit/512K x 16-Bit) 3.0 Volt-only Boot Sector Flash memory manufactured by Cypress Semiconductor Corp using 110 nm process technology. It features a 55 ns access time and operates within a voltage range of 3.0 to 3.6 V. The device is housed in a 48-ball Fine-pitch BGA package with a bottom boot sector configuration and supports industrial temperature ranges.

Memory IC Feature Summary

Supports single power supply operation for read, program, and erase functions without requiring external high voltages.
Includes a Secured Silicon Sector region allowing permanent identification via an Electronic Serial Number.
Features flexible sector architecture with hardware protection mechanisms to lock sectors against unauthorized programming or erasure.
Complies with Common Flash Interface (CFI) standards to facilitate host software reconfiguration.

Memory IC Applications

Battery-powered applications requiring low voltage operation
Systems needing secure identification through locked silicon sectors
Embedded firmware storage requiring top or bottom boot block configurations

Memory IC Procurement Notes

Verify the specific ordering suffix 'R2' confirms the bottom boot sector configuration and CFI support as documented. Confirm the 'F' material set indicates lead-free composition. Ensure the 'I' temperature grade matches the required industrial operating range. Cross-reference the manufacturer part number with current Infineon portfolios due to corporate integration.

Memory IC Selection Notes

Select this component when a 55 ns access speed is required for the 8-Mbit density. Choose the BGA package for space-constrained designs compared to TSOP options. Ensure the system design accommodates the 3.0V to 3.6V voltage range. Verify that the bottom boot sector layout aligns with the target application's code execution requirements.

Memory IC Part Context

This device belongs to the S29AL008J family of 3.0 Volt-only Boot Sector Flash memories. Originally developed by Cypress Semiconductor, it is now part of the Infineon Technologies product portfolio. The family utilizes 110 nm process technology and maintains compatibility with JEDEC standards for pinout and command sets.
