S2ALP33025-125.000-H-X-R

Oscillators Overview

The S2ALP33025-125.000-H-X-R is a surface-mount crystal oscillator manufactured by Aker Technology Corp. It operates at a standard frequency of 125 MHz with HCSL output levels. The device supports a supply voltage range of 1.8V to 3.3V and features an enable/disable control function. It utilizes a 6-SMD, no-lead package for surface mounting applications.

Oscillators Feature Summary

• Generates a 125 MHz clock signal using HCSL output technology
• Includes hardware enable and disable control functionality
• Operates within a wide supply voltage range from 1.8V to 3.3V

Oscillators Applications

• High-speed digital interface clock generation
• Data communication equipment timing sources
• Server and storage system clock distribution

Oscillators Procurement Notes

Verify the specific suffix codes against official manufacturer documentation to ensure correct output type and voltage compatibility. Confirm that the 6-pin SMD package dimensions match the target PCB footprint requirements. Check for RoHS compliance status in the latest datasheet revision before finalizing procurement specifications.

Oscillators Selection Notes

Select this component when HCSL signaling is required for noise immunity in high-frequency designs. Ensure the design supports the 1.8V to 3.3V operating range. Consider the enable pin requirement for power management strategies during system idle states compared to always-on oscillator alternatives.

Oscillators Part Context

This model belongs to the S2A LP series of low-power oscillators from Aker Technology. It is designed for compact electronic systems requiring precise timing. The part integrates the resonator and driver circuit into a single surface-mount package for simplified board layout.

Oscillators Replacement Considerations

Direct substitutes must match the 125 MHz frequency, HCSL output, 6-pin package, and enable feature. Verify electrical parameters such as load capacitance and drive level compatibility with the host circuit.
