S2M025T-12.000-X-R

Oscillators Overview

The S2M025T-12.000-X-R is a standard frequency HCMOS output clock oscillator manufactured by Aker Technology Corp. It operates at a nominal frequency of 12 MHz and utilizes a surface-mount package with four pins. The device supports an enable/disable function and functions within a supply voltage range of 1.62 V to 3.63 V, with a nominal voltage of 2.5 V. It is compliant with RoHS standards.

Oscillators Feature Summary

• Generates a stable 12 MHz clock signal using HCMOS output technology for digital circuit synchronization.
• Includes an integrated enable and disable control function to manage power consumption and signal availability.
• Designed for surface-mount installation in compact electronic assemblies.

Oscillators Applications

• Digital system clock generation
• Microprocessor timing references
• Communication interface synchronization

Oscillators Procurement Notes

Verify the specific suffix 'X-R' against the manufacturer's current documentation to confirm pinout configuration and electrical tolerances. Ensure the selected variant matches the required supply voltage range and load capacitance specifications for the target application circuit design.

Oscillators Selection Notes

Select this component when a precise 12 MHz reference is required for HCMOS-compatible logic circuits. Consider the enable/disable feature for systems requiring dynamic clock management. Verify that the operating temperature range and physical dimensions fit the constraints of the intended PCB layout.

Oscillators Part Context

This oscillator belongs to the S2M series of surface-mount crystal oscillators from Aker Technology Corp. These components are designed to replace discrete crystal and resonator circuits by providing a ready-made clock signal source in a standardized footprint.

Oscillators Replacement Considerations

S2M025T-12.000-R is listed as a related variant. Cross-reference datasheets to verify if the non-X suffix differs in tolerance or packaging before substitution.
