S35010-4.000-A-X1-R

Oscillators Overview

The S35010-4.000-A-X1-R is a surface-mount clock oscillator manufactured by Aker Technology Corp. It operates at a nominal frequency of 4.000 MHz with a CMOS output level. The device supports a supply voltage range from 1.8V to 5.0V and features a standard 3225 package size measuring 3.2mm in length, 2.5mm in width, and 1.1mm in height. It includes four pins and complies with RoHS standards for lead-free construction.

Oscillators Feature Summary

• CMOS output signal generation
• Surface mount installation type
• Wide operating temperature range

Oscillators Applications

• Microprocessor-based applications
• Telecommunications equipment
• Data storage systems

Oscillators Procurement Notes

Verify the specific part number against official manufacturer documentation to confirm electrical parameters and mechanical dimensions. Ensure compatibility with target supply voltage levels and load requirements. Cross-reference datasheets for accurate pinout configurations and soldering profiles prior to integration into final designs.

Oscillators Selection Notes

Select this component based on required frequency stability and package constraints. Consider the CMOS output drive capability and supply voltage flexibility when designing power circuits. Verify thermal performance within the specified operating temperature range for the intended application environment.

Oscillators Part Context

This oscillator belongs to the S3 series of surface-mount timing devices produced by Aker Technology. The company specializes in frequency control solutions established since 1990. This specific model represents a standard clock oscillator variant designed for general electronic timing needs.

Oscillators Replacement Considerations

Consult official cross-reference tools or distributor databases for verified substitute part numbers. Ensure any replacement matches the original frequency, package dimensions, and output logic family.
