S3A3305-156.250-P-X2-R

Oscillators Overview

The S3A3305-156.250-P-X2-R is a standard crystal oscillator manufactured by Aker Technology Corp, operating at a frequency of 156.25 MHz. It utilizes LVPECL output levels with a 3.3V supply voltage and features enable/disable functionality. The component is housed in a 6-SMD, no lead package measuring 3.20mm x 2.50mm. It supports an operating temperature range from -40°C to 105°C and belongs to the S3A series.

Oscillators Feature Summary

• LVPECL output configuration for high-speed digital applications
• Integrated enable and disable control capability
• Surface-mount design in a compact 6-SMD no-lead package

Oscillators Applications

• High-speed data transmission systems
• Telecommunications equipment clocking
• Network infrastructure timing sources

Oscillators Procurement Notes

Verify the specific suffix codes against official manufacturer documentation to ensure correct output type and voltage levels. Confirm that the 6-SMD package dimensions align with PCB footprint requirements. Check RoHS compliance status through certified datasheets rather than distributor summaries. Ensure the enable/disable pinout matches the target circuit design before procurement.

Oscillators Selection Notes

Select this component when LVPECL signaling is required for 156.25 MHz applications. Consider the wide industrial temperature range for harsh environments. Evaluate the enable feature for power management needs. Compare physical dimensions against available board space constraints. Verify compatibility with 3.3V logic interfaces in the target system architecture.

Oscillators Part Context

This oscillator belongs to the S3A series from Aker Technology Corp, designed for surface-mount assembly. The series typically offers standardized frequencies for common networking and communication standards. The S3A3305 variant specifically targets applications requiring precise timing at 156.25 MHz with low jitter performance typical of modern clock generators.

Oscillators Replacement Considerations

Direct substitutes include other 156.25 MHz LVPECL oscillators in similar packages from compatible manufacturers. Verify electrical parameters such as load capacitance and drive strength. Ensure thermal characteristics match the original specifications. Cross-reference pinouts to confirm functional equivalence without redesign.
