S3M05T-8.000-R

Oscillators Overview

The S3M05T-8.000-R is a standard crystal oscillator (XO) manufactured by Aker Technology Corp, operating at a fixed frequency of 8.000 MHz. It utilizes HCMOS output logic and supports a supply voltage range of 1.62V to 3.63V. The component features an enable/disable control function for power management. It is housed in a compact 4-SMD, no lead surface-mount package, designed for integration into electronic circuits requiring precise timing signals.

Oscillators Feature Summary

• HCMOS output interface for digital signal compatibility
• Integrated enable and disable control functionality
• Surface-mount package design for automated assembly

Oscillators Applications

• Embedded systems requiring clock synchronization
• Digital communication interfaces
• Microcontroller timing sources

Oscillators Procurement Notes

Verify the specific manufacturer documentation for the S3M05T series to confirm electrical tolerances and pin configurations. Ensure that the selected variant matches the required voltage levels and output logic standards for the target application circuit. Cross-reference the part number with official distributor catalogs to confirm current availability and compliance status before procurement.

Oscillators Selection Notes

Select this component when a stable 8 MHz reference is needed with low-power HCMOS compatibility. Consider the 1.62V to 3.63V operating range to ensure compatibility with the system's power rails. The enable/disable feature allows for dynamic power control, which is beneficial for battery-operated or energy-efficient designs requiring periodic clock activation.

Oscillators Part Context

This oscillator belongs to the S3M05T series from Aker Technology Corp, which provides surface-mount crystal oscillators for general-purpose timing applications. The series is characterized by its small form factor and standard HCMOS outputs, suitable for modern PCB layouts where space constraints are significant.

Oscillators Replacement Considerations

Direct substitutes must match the 8 MHz frequency, HCMOS output type, and 4-SMD no-lead package dimensions. Verify voltage compatibility within the 1.62V to 3.63V range. Check for equivalent enable/disable functionality if power management is critical to the design.
