S4B-ZR-SM2-TF

Headers, Male Pins Overview

The S4B-ZR-SM2-TF is a surface mount right-angle header connector from the JST ZH series. It features a 1.50mm pitch and provides two positions for board-to-wire connections. The component utilizes pin lock fastening and square contact shapes with tin plating on both mating and post surfaces. Constructed with brass contacts and PA6T insulation, it supports a rated current of 1A at 50V. The housing is natural-colored, meets UL94 V-0 flammability standards, and operates within a temperature range of -25°C to 85°C.

Headers, Male Pins Feature Summary

• Surface mount right-angle design for compact PCB integration
• Pin lock mechanism ensures secure mating stability
• Fixed tail characteristics facilitate automated assembly processes

Headers, Male Pins Applications

• Consumer electronics internal wiring
• Communication equipment circuit boards
• Computer peripheral interconnections

Headers, Male Pins Procurement Notes

Verify the specific suffix configuration against official JST documentation to ensure compatibility with intended mating components. Confirm that the ordering part number matches the required packaging format, such as tape and reel or cut tape, as specified in the manufacturer's catalog. Cross-reference the RoHS compliance status and material specifications with current regulatory requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this connector when a low-profile, right-angle surface mount solution is required for 1.50mm pitch applications. Ensure the mating cable harness utilizes compatible ZH series housings and terminals. Verify that the PCB footprint dimensions align with the specified solder tail geometry and that the operational voltage and current ratings meet the system's electrical demands without exceeding limits.

Headers, Male Pins Part Context

This component belongs to the JST ZH series, which specializes in high-density, small-pitch connectors designed for modern electronic devices. The ZH series offers various configurations including straight and right-angle headers, catering to space-constrained designs. The S4B-ZR-SM2-TF specifically addresses needs for reliable, compact interconnections in portable and industrial electronics where board real estate is limited.

Headers, Male Pins Replacement Considerations

Direct substitutes include other JST ZH series right-angle headers with identical 1.50mm pitch and two-position configuration, such as B2B-ZR-SM2-TF variants. Ensure any replacement maintains the same pin count, mounting style, and insulation material properties to guarantee mechanical and electrical compatibility.
