S53305-20.000-X1-R

$1.22

Description：OSC 20MHZ 3.3V CMOS SMD
Series：S5
Mfr：Aker Technology Corp
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:bc7e016edffb Category: Oscillators Brand: Aker Technology Corp

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

S53305-20.000-X1-R is listed in the Oscillators range at ChipApex. The manufacturer field lists Aker Technology Corp. Its product description is OSC 20MHZ 3.3V CMOS SMD. Review the specifications below when checking this part for your BOM.

Oscillators specifications for S53305-20.000-X1-R

Description：OSC 20MHZ 3.3V CMOS SMD
Series：S5
Mfr：Aker Technology Corp
Package：Tape & Reel (TR),Cut Tape (CT)
Base Resonator：Crystal
Type：XO (Standard)
Frequency：20 MHz
Function：Enable/Disable
Output：HCMOS
Voltage - Supply：3.3V
Frequency Stability：±50ppm
Absolute Pull Range (APR)：-
Operating Temperature：-40°C ~ 85°C
Spread Spectrum Bandwidth：-
Current - Supply (Max)：12mA
Ratings：-
Mounting Type：Surface Mount
Package / Case：4-SMD, No Lead
Size / Dimension：0.197" L x 0.126" W (5.00mm x 3.20mm)
Height - Seated (Max)：0.051" (1.30mm)
Supplier Device Package：-

Oscillators datasheet and documents for S53305-20.000-X1-R

S53305-20.000-X1-R

Oscillators Overview

The S53305-20.000-X1-R is a 20 MHz HCMOS crystal oscillator manufactured by Aker Technology Corp. It operates on a 3.3V supply voltage with a maximum current consumption of 12mA. The device features ±50ppm frequency stability and includes an Enable/Disable control function. It is housed in a compact 4-SMD, No Lead package measuring 5mm x 3.2mm x 0.95mm. The component supports an operating temperature range from -40°C to 85°C.

Oscillators Feature Summary

HCMOS output signal generation
Integrated enable/disable functionality
Compact surface-mount design

Oscillators Applications

General clock timing circuits
Embedded system synchronization
Digital logic interface timing

Oscillators Procurement Notes

Verify the manufacturer designation carefully, as some distributor listings incorrectly associate this part number with Texas Instruments. Confirm the specific suffix 'X1' matches the required enable/disable feature set. Ensure the 3.3V supply requirement aligns with your target circuit design before procurement.

Oscillators Selection Notes

Select this component when a standard 20MHz clock source with low power consumption is required. The HCMOS output level is suitable for direct interfacing with digital logic families. Consider the ±50ppm stability specification against your system's jitter tolerance requirements.

Oscillators Part Context

This oscillator belongs to the S5 series of surface-mount devices from Aker Technology. It utilizes a base crystal resonator for frequency generation. The part is designed for general-purpose applications rather than automotive or high-reliability specialized environments.
