S6BP502A00SN2B000
Search Product
Search Post
— IC芯片 | 连接器 | 传感器 | 被动器件 —
Consult the customer manager about the wholesale price.
consultation hotline：86-132-6715-2157
email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.
Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.
Product Detailed Parameters
- Description：ANALOG
- Series：-
- Mfr：Infineon Technologies
- Package：Tape & Reel (TR),Cut Tape (CT)
- Output Type：Transistor Driver
- Function：Step-Up, Step-Down
- Output Configuration：Positive
- Topology：Buck, Boost
- Number of Outputs：3
- Output Phases：1
- Voltage - Supply (Vcc/Vdd)：2.5V ~ 42V
- Frequency - Switching：-
- Duty Cycle (Max)：100%
- Synchronous Rectifier：No
- Clock Sync：Yes
- Serial Interfaces：-
- Control Features：Enable
- Operating Temperature：-40°C ~ 105°C (TA)
- Mounting Type：Surface Mount
- Package / Case：32-VFQFN Exposed Pad
- Supplier Device Package：32-QFN (5x5)
- Grade：-
- Qualification：-
Download product information
Overview
The S6BP502A00SN2B000 is a specialized automotive power management IC (PMIC) designed for in-vehicle applications. It integrates three DC/DC converter channels, including a high-voltage buck controller and step-up/step-down regulators, within a compact PG-VQFN-32-20 package. The device supports input voltages typical for automotive systems and operates across an extended temperature range suitable for harsh environments.
Feature Summary
- Integrates multiple DC/DC conversion functions including buck and boost capabilities
- Designed specifically for automotive-grade reliability and performance
- Utilizes a compact surface-mount package to minimize board space
Applications
- Automotive infotainment systems
- In-vehicle networking components
- Automotive dashboard clusters
Procurement Notes
Verify the specific suffix 'SN2B000' against official Infineon documentation to confirm exact pinout and configuration. Confirm RoHS compliance status and current lifecycle stage, as automotive PMICs may have long-term availability commitments or end-of-life notices. Ensure the selected variant matches the required thermal and electrical specifications for the target application.
Selection Notes
Select this component when a multi-channel PMIC solution is required for automotive electronics. Consider the integrated buck and boost controllers if space constraints prevent using discrete converters. Verify that the operating voltage range and current requirements of the load devices align with the IC's specified output capabilities and thermal performance limits.
Part Context
This part belongs to Infineon's S6BP series of specialized automotive PMICs. These components are engineered to simplify power distribution in complex vehicle architectures by combining multiple regulation stages into a single chip, reducing component count and improving system reliability compared to discrete solutions.
