S73305T-25.000-X-15-R

$0.92

Description：XTAL OSC XO 25.0000MHZ HCMOS SMD
Series：S7
Mfr：Aker Technology Corp
Package：Tape & Reel (TR),Cut Tape (CT)

SKU:bc2353ee4e6b Category: Oscillators Brand: Aker Technology Corp

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

S73305T-25.000-X-15-R is listed in the Oscillators range at ChipApex. The manufacturer field lists Aker Technology Corp. Its product description is XTAL OSC XO 25.0000MHZ HCMOS SMD. Review the specifications below when checking this part for your BOM.

Oscillators specifications for S73305T-25.000-X-15-R

Description：XTAL OSC XO 25.0000MHZ HCMOS SMD
Series：S7
Mfr：Aker Technology Corp
Package：Tape & Reel (TR),Cut Tape (CT)
Base Resonator：Crystal
Type：XO (Standard)
Frequency：25 MHz
Function：Enable/Disable
Output：HCMOS
Voltage - Supply：3.3V
Frequency Stability：±50ppm
Absolute Pull Range (APR)：-
Operating Temperature：-40°C ~ 85°C
Spread Spectrum Bandwidth：-
Current - Supply (Max)：12mA
Ratings：-
Mounting Type：Surface Mount
Package / Case：4-SMD, No Lead
Size / Dimension：0.276" L x 0.197" W (7.00mm x 5.00mm)
Height - Seated (Max)：0.055" (1.40mm)
Supplier Device Package：-

Oscillators datasheet and documents for S73305T-25.000-X-15-R

S73305T-25.000-X-15-R

Oscillators Overview

The S73305T-25.000-X-15-R is a surface-mount HCMOS clock oscillator from the S7 series, manufactured by Aker Technology Corp. It operates at a nominal frequency of 25 MHz with a temperature stability of ±50 ppm. The device supports a supply voltage range of 1.8V to 3.3V and features a low-profile 4-pin SMD package measuring 7mm x 5mm x 1.3mm. It includes an enable/disable control function and complies with RoHS standards.

Oscillators Feature Summary

Provides stable 25 MHz HCMOS clock signals for digital circuits
Integrates hardware enable and disable control functionality
Designed for low-profile surface-mount assembly processes

Oscillators Applications

Embedded communication systems requiring precise timing
Digital signal processing circuitry
Microcontroller clock sources

Oscillators Procurement Notes

Verify that the specific suffix 'T' and '-R' correspond to the required tape-and-reel packaging format rather than bulk or tray configurations. Confirm the operating voltage aligns with the 3.3V specification, as the S7 series also supports 1.8V variants. Ensure the lead-free RoHS compliance meets environmental requirements for the target assembly line.

Oscillators Selection Notes

Select this component when a 25 MHz output is strictly required alongside hardware enable/disable capabilities. The S73305T variant differs from the standard S73305 model by including the control pin. Choose this part over other S7 frequencies if the system architecture specifically demands 25 MHz synchronization without additional frequency multiplication.

Oscillators Part Context

This oscillator belongs to the S7 series of surface-mount crystal oscillators. The series offers various frequencies up to 100 MHz with ±50 ppm stability. The S73305T designation indicates the inclusion of an enable/disable feature, distinguishing it from the base S73305 model which lacks this control interface.
