S765N-868 is listed in the Antennas RF range at ChipApex. The manufacturer field lists Nearson Inc.. Its product description is 867-869MHZ N JACK M2M OUTDOOR AN. Review the specifications below when checking this part for your BOM.
Antennas RF specifications for S765N-868
- Description：867-869MHZ N JACK M2M OUTDOOR AN
- Series：-
- Mfr：Nearson Inc.
- Package：Bulk
- RF Family/Standard：-
- Frequency Group：UHF (300MHz ~ 1GHz)
- Frequency (Center/Band)：868MHz
- Frequency Range：867MHz ~ 869MHz
- Antenna Type：Dome
- Number of Bands：1
- VSWR：2
- Return Loss：-
- Gain：2dBi
- Features：-
- Termination：N Type Male
- Ingress Protection：-
- Grade：-
- Qualification：-
- Mounting Type：Panel Mount
- Height (Max)：3.039" (77.20mm)
- Applications：-
- Power - Max：-
Antennas RF datasheet and documents for S765N-868
Antennas RF Overview
The S765N-868 is an outdoor RF antenna manufactured by Nearson Inc., designed for operation within the 867-869 MHz frequency band. It features a dome shape and utilizes an N-type male connector for termination. The unit is engineered for panel mounting applications, with a maximum height of 3.039 inches (77.20 mm). This component serves as a specialized antenna solution for industrial or M2M communication systems requiring robust outdoor performance in the specified UHF range.
Antennas RF Feature Summary
- Dome-shaped design suitable for outdoor environments
- Panel mounting configuration for secure installation
- N-type male connector interface
Antennas RF Applications
- Industrial M2M communication systems
- Outdoor IoT sensor networks
- UHF telemetry links
Antennas RF Procurement Notes
Verify the specific frequency band requirement against the 867-869 MHz specification before procurement. Confirm that the N-type male connector matches the receiving equipment interface. Ensure the panel mounting dimensions accommodate the 77.20 mm height constraint in the intended enclosure design.
Antennas RF Selection Notes
Select this model when a fixed outdoor antenna is required for the 867-869 MHz band. The N-type male interface dictates compatibility with standard coaxial cables featuring N-type female connectors. Consider the dome form factor for aerodynamic or low-profile aesthetic requirements in outdoor deployments.
Antennas RF Part Context
This part belongs to the Nearson S765N series of RF antennas. The series includes variants such as the S765N-915, which operates at 915 MHz. These components share similar physical construction characteristics, including the dome shape and N-type male termination, differing primarily in their resonant frequency bands.
Antennas RF Replacement Considerations
The S765N-915 is a related variant within the same product family but operates at a different frequency (915 MHz) and is not electrically interchangeable for 868 MHz applications without system redesign.
