S7A3303-25.000-P-R

Oscillators Overview

The S7A3303-25.000-P-R is a standard crystal oscillator manufactured by Aker Technology Corp, designed for precision frequency generation in electronic circuits. It operates at a nominal frequency of 25 MHz and utilizes LVPECL (Low Voltage Positive Emitter Coupled Logic) output signaling to ensure high-speed data integrity and low jitter performance. The device requires a 3.3V supply voltage and incorporates an enable/disable control function, allowing for power management and system synchronization capabilities. It is housed in a compact 6-SMD, No Lead package, facilitating surface-mount assembly on printed circuit boards while maintaining robust mechanical stability.

Oscillators Feature Summary

• LVPECL output interface for high-speed signal transmission
• Integrated enable/disable control functionality
• Compact 6-SMD no-lead surface mount package

Oscillators Applications

• Embedded communication systems
• Signal acquisition platforms
• FPGA clock sources

Oscillators Procurement Notes

Verify the manufacturer part number S7A3303-25.000-P-R against official Aker Technology Corp documentation to confirm authenticity. Ensure the ordering suffix matches the required specifications, as variations may exist. Cross-reference with authorized distributors to validate supply chain integrity and avoid counterfeit components.

Oscillators Selection Notes

Select this component when LVPECL outputs are required for 25 MHz applications. Confirm that the 3.3V operating voltage aligns with the system design. Evaluate the 6-SMD package dimensions against PCB layout constraints. Consider the enable/disable feature if power cycling or clock gating is necessary for the specific application requirements.

Oscillators Part Context

This oscillator belongs to the S7A series from Aker Technology Corp, which specializes in frequency control products. The series includes various models with different frequencies and output types, such as the S7A3305-125.000-P-R. Aker Technology has been established since 1990, providing crystal and oscillator solutions for global electronics industries.

Oscillators Replacement Considerations

Check for direct substitutes within the S7A series, such as the S7A3305-125.000-P-R, noting differences in frequency and output type. Verify pin compatibility and electrical parameters before substitution.
