SAX32410EY4A-30.000M

Crystals Overview

The SAX32410EY4A-30.000M is a surface-mount crystal oscillator manufactured by Suntsu Electronics, Inc. It operates at a nominal frequency of 30.000 MHz with a frequency tolerance of ±15ppm and stability of ±100ppm. The component features a load capacitance of 10pF and an equivalent series resistance (ESR) of 60 Ohms. It utilizes a 4-SMD, No Lead package with dimensions of 3.2mm x 2.5mm. The device supports a wide operating temperature range from -40°C to +105°C and is available in tape and reel packaging.

Crystals Feature Summary

• Surface-mount design for automated assembly
• Wide industrial temperature operation capability
• Compact 4-SMD no-lead footprint

Crystals Applications

• Clock generation for microcontrollers
• Frequency reference for communication modules
• Timing circuits in consumer electronics

Crystals Procurement Notes

Verify the specific suffix EY4A against the manufacturer's current datasheet to confirm pinout and loading capacitance requirements. Ensure the ordering quantity matches the tape and reel specifications provided in the official documentation. Confirm that the ±15ppm tolerance meets the system timing accuracy needs before finalizing procurement.

Crystals Selection Notes

Select this component when a 30 MHz frequency is required with a compact 3.2mm x 2.5mm SMD footprint. Consider the 60 Ohm ESR and 10pF load capacitance for circuit matching. The wide temperature range makes it suitable for harsh environments compared to commercial grade alternatives.

Crystals Part Context

This part belongs to the SAX series of ceramic surface-mount crystals from Suntsu Electronics. It shares the standard 4-pad no-lead package format common to this family, differing primarily in frequency and electrical parameters such as ESR and tolerance levels defined by the specific model suffix.

Crystals Replacement Considerations

Direct substitutes must match the 30 MHz frequency, 10pF load capacitance, and 3.2x2.5mm package. Verify ESR compatibility to ensure oscillation startup reliability. Cross-reference with other manufacturers offering similar 4-SMD crystal packages.
