SBH51-LPSE-D07-ST-BK

Headers, Male Pins Overview

The SBH51-LPSE-D07-ST-BK is a fully shrouded box header from Sullins Connector Solutions, designed for board-to-board interconnections. It features a 1.00mm (0.039 inch) pitch with two rows of male pins, totaling 14 contacts. The connector utilizes surface mount termination and includes a four-wall shroud to minimize mismatching risks. Constructed with liquid crystal polymer insulation and phosphor bronze contacts, it supports a temperature range of -40°C to 125°C.

Headers, Male Pins Feature Summary

• Fully shrouded design with four walls to prevent incorrect mating
• Surface mount installation for automated assembly efficiency
• High-density 1.00mm pitch configuration for space-constrained applications

Headers, Male Pins Applications

• High-density electronic assemblies requiring reliable board-to-board connections
• Embedded systems utilizing microcontrollers or similar components
• Industrial control boards needing robust shrouded header protection

Headers, Male Pins Procurement Notes

Verify the specific suffix 'ST' against official datasheets to confirm lead angle specifications, as variations exist within the SBH51 series. Ensure compatibility with RoHS3 compliance requirements if mandated by project standards. Cross-reference the pin count and row configuration to match the intended PCB footprint accurately before ordering.

Headers, Male Pins Selection Notes

Select this component when a fully shrouded, high-reliability header is required to eliminate mating errors in dense layouts. The 1.00mm pitch offers a balance between signal density and mechanical stability. Consider the surface mount profile for automated manufacturing processes and ensure the operating temperature range meets the environmental demands of the final application.

Headers, Male Pins Part Context

This part belongs to the SBH51 series of fully shrouded box headers manufactured by Sullins Connector Solutions. The series is engineered to enhance design flexibility while reducing vendor counts. These connectors are characterized by their durability and ability to support high-density environments through precise 1.00mm spacing and robust shielding features.

Headers, Male Pins Replacement Considerations

Direct substitutes within the same series include variants with different pin counts such as SBH51-LPSE-D10-SP-BK or SBH51-LPSE-D20-SM-BK. Verify that any replacement maintains the identical 1.00mm pitch, shrouding style, and mounting type to ensure mechanical and electrical compatibility.
