SBT01M-09

SBT01M-09 is listed in the DC DC Converters range at ChipApex. The manufacturer field lists MEAN WELL USA Inc.. Its product description is DC DC CONVERTER 9V 1W. Review the specifications below when checking this part for your BOM.

DC DC Converters specifications for SBT01M-09

• Description：DC DC CONVERTER 9V 1W
• Series：SBT01 (1W)
• Mfr：MEAN WELL USA Inc.
• Package：Tube
• Type：Isolated Module
• Number of Outputs：1
• Voltage - Input (Min)：10.8V
• Voltage - Input (Max)：13.2V
• Voltage - Output 1：9V
• Voltage - Output 2：-
• Voltage - Output 3：-
• Voltage - Output 4：-
• Current - Output (Max)：111mA
• Power (Watts)：1 W
• Voltage - Isolation：1 kV
• Applications：ITE (Commercial)
• Features：OCP, SCP
• Operating Temperature：-40°C ~ 85°C (With Derating)
• Efficiency：75%
• Mounting Type：Surface Mount
• Package / Case：8-SMD Module
• Size / Dimension：0.50" L x 0.30" W x 0.25" H (12.7mm x 7.5mm x 6.3mm)
• Supplier Device Package：-
• Control Features：-
• Approval Agency：-
• Standard Number：-
• Grade：-
• Qualification：-

DC DC Converters datasheet and documents for SBT01M-09
