SC-01-50G

$2.63

Description：CMC 5MH 1A 2LN TH
Series：SC-G
Mfr：KEMET
Package：Bulk

SKU:499be3a6570f Category: Common Mode Chokes Brand: KEMET

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SC-01-50G is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists KEMET. Its product description is CMC 5MH 1A 2LN TH. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for SC-01-50G

Description：CMC 5MH 1A 2LN TH
Series：SC-G
Mfr：KEMET
Package：Bulk
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：1A
DC Resistance (DCR) (Max)：150mOhm
Voltage Rating - DC：250V
Voltage Rating - AC：250V
Operating Temperature：-40°C ~ 105°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：0.689" Dia x 0.551" W (17.50mm x 14.00mm)
Height (Max)：0.689" (17.50mm)
Package / Case：Vertical, No Base, 4 PC Pin
Inductance @ Frequency：5 mH @ 100 kHz
Impedance @ Frequency：-

Common Mode Chokes datasheet and documents for SC-01-50G

SC-01-50G

Common Mode Chokes Overview

The KEMET SC-01-50G is a single-channel common mode choke designed for through-hole PCB mounting. It features an inductance of 5 mH and supports a maximum DC current of 1 A. The component has a maximum DC resistance of 150 mΩ and operates within a temperature range of -25°C to +80°C. Rated for 250 V, it utilizes nickel-zinc ferrite core material and meets UL 94 V-0 flammability standards.

Common Mode Chokes Feature Summary

Provides effective common mode noise suppression for AC line applications
Constructed with nickel-zinc ferrite core material for stable performance
Designed for reliable through-hole PCB integration

Common Mode Chokes Applications

AC line filtering in electronic equipment
Common mode noise suppression circuits
Power supply input stages

Common Mode Chokes Procurement Notes

Verify the specific suffix code against official KEMET documentation to confirm exact electrical tolerances and packaging details. Ensure the procurement channel provides valid RoHS compliance certificates. Cross-reference the manufacturer part number with authorized distributor databases to prevent counterfeit components. Confirm that the requested quantity matches the standard factory tray packaging specifications.

Common Mode Chokes Selection Notes

Select this component when a 5 mH inductance value is required for common mode interference reduction. The 1 A current rating suits low-power AC line applications. Verify that the through-hole footprint dimensions align with the target PCB layout. Ensure the operating environment temperature remains within the specified -25°C to +80°C range for optimal reliability.

Common Mode Chokes Part Context

This component belongs to the KEMET SC series of common mode chokes. The series offers various inductance values tailored for different noise suppression requirements. These filters are engineered for general-purpose electronic applications requiring robust EMI mitigation on AC lines.
