SC-05-100JV

$5.34

Description：CMC 15MH 5A 2LN TH
Series：SC-JV
Mfr：KEMET
Package：Tray

SKU:7d94f6ad4dd8 Category: Common Mode Chokes Brand: KEMET

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SC-05-100JV is listed in the Common Mode Chokes range at ChipApex. The manufacturer field lists KEMET. Its product description is CMC 15MH 5A 2LN TH. Review the specifications below when checking this part for your BOM.

Common Mode Chokes specifications for SC-05-100JV

Description：CMC 15MH 5A 2LN TH
Series：SC-JV
Mfr：KEMET
Package：Tray
Filter Type：Power Line
Number of Lines：2
Current Rating (Max)：5A
DC Resistance (DCR) (Max)：-
Voltage Rating - DC：250V
Voltage Rating - AC：250V
Operating Temperature：-40°C ~ 105°C
Ratings：-
Approval Agency：-
Features：-
Mounting Type：Through Hole
Size / Dimension：1.378" L x 0.984" W (35.00mm x 25.00mm)
Height (Max)：1.575" (40.00mm)
Package / Case：Vertical, 4 PC Pin
Inductance @ Frequency：15 mH @ 16 kHz
Impedance @ Frequency：-

Common Mode Chokes datasheet and documents for SC-05-100JV

SC-05-100JV

Common Mode Chokes Overview

The KEMET SC-05-100JV is a through-hole common mode choke designed for power line filtering. It features an inductance of 15 mH at 16 kHz and supports a maximum DC current of 5 A. The component has a maximum DC resistance of 100 mOhms and operates within a temperature range of -25°C to +120°C. Rated for 250 VAC, it utilizes a two-wire configuration to suppress common mode electromagnetic interference in electronic circuits.

Common Mode Chokes Feature Summary

Designed for effective suppression of common mode electromagnetic interference
Constructed for reliable through-hole mounting on printed circuit boards
Engineered specifically for use as a power line filter

Common Mode Chokes Applications

Power line filtering in electronic equipment
Common mode noise suppression in AC/DC circuits
Electromagnetic interference mitigation in industrial applications

Common Mode Chokes Procurement Notes

Verify the specific part number SC-05-100JV against official KEMET documentation to confirm electrical ratings and physical dimensions. Ensure compatibility with your circuit's voltage and current requirements before integration. Cross-reference datasheets for any recent manufacturing changes or obsolescence notices to guarantee supply chain stability and technical accuracy.

Common Mode Chokes Selection Notes

Select this component when a robust through-hole solution is required for high-current power line filtering. The 5 A rating and 15 mH inductance make it suitable for applications needing significant common mode noise attenuation. Consider the operating temperature range and physical footprint constraints during the design phase to ensure proper board layout and thermal management.

Common Mode Chokes Part Context

This component belongs to the SC series of common mode chokes from KEMET. These devices are engineered for durability and consistent performance in demanding environments. The SC-05-100JV variant specifically targets applications requiring high current handling capabilities alongside effective EMI suppression, fitting into broader power management and signal integrity strategies.
