SC-09-D035JH

Common Mode Chokes Overview

The KEMET SC-09-D035JH is a through-hole common mode choke from the SC-D series. It features a 35 uH inductance and supports a maximum DC current of 9 A with a DCR of 7.8 mOhms. Rated for 250 V, this unshielded ferrite core component operates between -40 C and +105 C.

Common Mode Chokes Feature Summary

• Provides high common mode noise suppression via ultra-high permeability design
• Utilizes nanocrystalline metal cores for enhanced performance
• Supports horizontal mounting via through-hole termination

Common Mode Chokes Applications

• Three-phase power line filtering
• Industrial motor drive EMI suppression
• Power supply input stages

Common Mode Chokes Procurement Notes

Verify the specific suffix JH against official KEMET documentation to confirm terminal base type and pin configuration. Ensure the selected variant matches the required voltage rating and current handling capacity for the target application circuit.

Common Mode Chokes Selection Notes

Select this component when high current handling up to 9 A is required alongside significant common mode attenuation. The SC-D series offers superior inductance density compared to standard ferrite chokes, making it suitable for compact power electronics designs.

Common Mode Chokes Part Context

This part belongs to the SC-D-J/JH series of common mode coils. These components are engineered for robust power applications, utilizing advanced core materials to achieve high inductance values within a standardized through-hole package format.

Common Mode Chokes Replacement Considerations

Consult the official KEMET datasheet for direct cross-references. Verify that any substitute maintains the 35 uH inductance, 9 A current rating, and compatible physical dimensions for PCB integration.
