Product Detailed Parameters
- Description：CMC 4.1MH 11A 2LN TH AEC-Q200
- Series：SCF-XV
- Mfr：KEMET
- Package：Tray
- Filter Type：Power Line
- Number of Lines：2
- Current Rating (Max)：11A
- DC Resistance (DCR) (Max)：7.72mOhm
- Voltage Rating - DC：1000V (1kV)
- Voltage Rating - AC：1000V (1kV)
- Operating Temperature：-40°C ~ 150°C
- Ratings：AEC-Q200
- Approval Agency：-
- Features：-
- Mounting Type：Through Hole
- Size / Dimension：1.516" L x 1.043" W (38.50mm x 26.50mm)
- Height (Max)：1.378" (35.00mm)
- Package / Case：Vertical, 4 PC Pin
- Inductance @ Frequency：4.1 mH @ 100 kHz
- Qualification：-
Download product information
Overview
The KEMET SCF25XV-110-1R4A013JV is a dual-line common mode choke designed for through-hole mounting. It features an inductance of 4.1 mH at 100 kHz and supports a maximum DC current of 11 A. The component has a low DC resistance of 7.72 mΩ and is rated for 1000 V. It complies with the AEC-Q200 automotive standard, ensuring reliability in demanding environments.
Feature Summary
- Dual-line configuration for effective noise suppression
- Automotive-grade qualification under AEC-Q200 standards
- Through-hole termination for robust mechanical stability
Applications
- Automotive power supply filtering
- High-voltage circuit noise reduction
- Industrial equipment EMI suppression
Procurement Notes
Verify the complete part number including suffixes to ensure correct specifications. Confirm that the AEC-Q200 certification is required for your specific application. Check datasheet details for thermal management requirements during installation. Ensure compatibility with existing PCB footprint dimensions before ordering.
Selection Notes
Select this component when high voltage isolation and automotive reliability are critical. The 11 A current rating suits high-power applications. Consider the 4.1 mH inductance value for specific frequency filtering needs. Verify space constraints for through-hole mounting against available board real estate.
Part Context
This component belongs to KEMET's SCF series of common mode chokes. It is engineered for automotive and industrial sectors requiring robust EMI performance. The design emphasizes durability and electrical efficiency in high-current scenarios.
Replacement Considerations
The SCR25XV-110-1R4A013JV is a related variant within the same family. Verify if the SCR version meets all electrical and mechanical requirements as a substitute.
