SCR25-070-1R1A070J

Overview

The KEMET SCR25-070-1R1A070J is a radial leaded common mode choke from the SCR25 series. It features an inductance of 7 mH at 10 kHz and a DC current rating of 7 A. The component has a maximum DC resistance of 34 mOhms and operates within a temperature range of -40°C to +120°C.

Feature Summary

• Provides common mode noise suppression for AC line applications
• Designed for high current handling with a 7 A DC rating
• Radial through-hole construction for standard PCB mounting

Applications

• AC line input filtering
• EMI suppression in power supplies
• General electromagnetic interference reduction

Procurement Notes

Verify the specific datasheet version for the SCR25-070-1R1A070J to confirm mechanical dimensions and thermal characteristics. Ensure the application environment stays within the specified -40°C to +120°C operating range. Confirm that the 7 A current rating meets the circuit requirements without exceeding thermal limits.

Selection Notes

Select this component when a 7 mH inductance is required for common mode noise attenuation in AC lines. The 7 A current rating suits moderate power applications. Verify that the radial lead spacing fits the target PCB layout and that the 34 mOhm DCR is acceptable for the system's voltage drop constraints.

Part Context

This part belongs to the KEMET SCR25 series of AC line filters. These chokes are engineered for robust performance in demanding environments, offering reliable EMI suppression for electronic equipment connected to AC mains power sources.

Replacement Considerations

Check for other parts in the SCR25 series with matching 7 mH inductance and 7 A current ratings. Verify physical footprint compatibility before substituting with components from different manufacturers.
