SCRH6D38-5R0

Fixed Inductors Overview

The SCRH6D38-5R0 is a fixed surface-mount inductor from the Signal Transformer SCRH6D38 series. It features a nominal inductance of 5 µH and a maximum DC resistance of 26 mΩ. The component supports a saturation current of 2.9 A and operates at a test frequency of 10 kHz. Designed for power applications, it utilizes a shielded nonstandard package suitable for PCB mounting.

Fixed Inductors Feature Summary

• High current handling capability with a saturation rating of 2.9 A
• Shielded construction to minimize magnetic radiation
• Low DC resistance for improved efficiency

Fixed Inductors Applications

• DC/DC converter circuits
• LED driver circuits
• Power supply modules

Fixed Inductors Procurement Notes

Verify the specific part number suffix against official manufacturer documentation to confirm electrical characteristics. Ensure compatibility with required thermal management and PCB footprint specifications before procurement. Cross-reference datasheet values for inductance and current ratings to avoid substitution errors.

Fixed Inductors Selection Notes

Select this component for designs requiring high current density in a compact form factor. Evaluate the 2.9 A saturation limit against peak load requirements. Consider the shielded design for EMI-sensitive environments. Confirm the 5 µH value aligns with circuit filtering needs.

Fixed Inductors Part Context

This component belongs to the SCRH6D38 series of high-current toroidal inductors by Signal Transformer. The series offers various inductance values and current ratings optimized for space-constrained power electronics. It is part of Bel Fuse's broader portfolio of magnetic components.

Fixed Inductors Replacement Considerations

Consult official cross-reference lists for verified substitutes. Ensure replacement parts match the 5 µH inductance, 2.9 A current rating, and 26 mΩ DCR specifications.
