SCT010T-D-20-10

Current Sense Transformers Overview

The SCT010T-D-20-10 is a current transformer manufactured by PowerUC Electronics, designed for accurate load current detection. It features a rated primary current of 20 A and provides an output voltage of 10 V with a tolerance of 2%. The device operates within a frequency range of 50 Hz to 1 kHz. It is classified as a free-hanging (in-line) component suitable for integration into monitoring circuits requiring precise AC current measurement.

Current Sense Transformers Feature Summary

• Provides isolated current sensing via magnetic induction
• Delivers a standardized 10 V output signal proportional to the 20 A input
• Supports wide frequency bandwidth from 50 Hz up to 1 kHz
• Constructed as a free-hanging in-line unit for direct circuit insertion

Current Sense Transformers Applications

• AC load current monitoring systems
• Energy metering and power analysis equipment
• Industrial control circuits requiring current feedback
• Smart grid infrastructure sensors

Current Sense Transformers Procurement Notes

Verify that the specific order matches the SCT010T-D-20-10 designation to ensure the correct 20 A/10 V ratio and 2% accuracy class. Confirm RoHS compliance status if required by project specifications. Check the MSL level 2 rating for moisture sensitivity handling during storage and assembly processes to prevent package damage.

Current Sense Transformers Selection Notes

Select this component when a non-invasive, isolated method for measuring alternating currents up to 20 A is required. The 10 V output simplifies interface design with downstream analog-to-digital converters or microcontrollers. Ensure the operating environment supports the specified 50 Hz to 1 kHz frequency range for optimal performance and minimal phase shift errors.

Current Sense Transformers Part Context

This part belongs to the SCT010T-D series of current transformers from PowerUC Electronics. These devices are engineered for reliable performance in applications demanding high accuracy and electrical isolation between the primary conductor and secondary measurement circuitry.

Current Sense Transformers Replacement Considerations

No public substitute part numbers are confirmed for this specific model. Replacement requires matching the 20 A primary rating, 10 V secondary output, and 50 Hz–1 kHz frequency response characteristics exactly.
