SCT010T-D-25-5 is listed in the Current Sense Transformers range at ChipApex. The manufacturer field lists PowerUC Electronics. Its product description is 25A/5V 2%. Review the specifications below when checking this part for your BOM.
Current Sense Transformers specifications for SCT010T-D-25-5
- Description：25A/5V 2%
- Series：SCT010
- Mfr：PowerUC Electronics
- Package：Bulk
- Frequency Range：50Hz ~ 1kHz
- Type：Non-Invasive (Split Core)
- Inductance：-
- ET (Volt-Time)：-
- Current Ratio：-
- DC Resistance (DCR)：-
- Ratings：-
- Mounting Type：Free Hanging (In-Line)
- Size / Dimension：1.024" L x 1.338" W (26.00mm x 34.00mm)
- Height - Seated (Max)：1.968" (50.00mm)
- Termination Style：Terminal Block
- Turns Ratio - Primary:Secondary：-
- Current Rating (Amps)：30 A
Current Sense Transformers datasheet and documents for SCT010T-D-25-5
Current Sense Transformers Overview
The SCT010T-D-25-5 is a current sense transformer manufactured by PowerUC Electronics, designed for non-invasive current monitoring applications. It features a split-core design that allows for easy installation around existing conductors without breaking the circuit. The device operates within a frequency range of 50Hz to 1kHz and supports a nominal current rating of 30A. It provides an output specification of 25A/5V with a tolerance of 2%, ensuring accurate signal representation for downstream processing.
Current Sense Transformers Feature Summary
- Non-invasive split-core construction enables installation without circuit interruption
- Optimized for frequency ranges between 50Hz and 1kHz
- Provides precise current sensing with defined output ratios
Current Sense Transformers Applications
- Industrial current monitoring systems
- Power quality analysis equipment
- Electrical protection relay circuits
Current Sense Transformers Procurement Notes
Verify component authenticity through authorized distributors or direct manufacturer channels. Confirm RoHS compliance status and moisture sensitivity level (MSL 2) prior to procurement. Ensure storage conditions align with specified humidity constraints to maintain operational integrity upon deployment.
Current Sense Transformers Selection Notes
Select this model when non-invasive measurement is required for AC currents up to 30A. Ensure the operating environment falls within the 50Hz to 1kHz frequency band. Verify that the downstream interface can accommodate the 5V output signal derived from the primary current flow.
Current Sense Transformers Part Context
This component belongs to the SCT010T series of current sense transformers. It is engineered for free-hanging in-line mounting configurations. The product line focuses on providing reliable electrical isolation and accurate current transformation for industrial and commercial power management applications.
Current Sense Transformers Replacement Considerations
Consult official datasheets for cross-reference compatibility. No specific substitute part numbers are publicly confirmed in available documentation. Verify pinout and electrical specifications before considering alternative components.
