SD103C-TP

Single Diodes Overview

The SD103C-TP is a Schottky barrier rectifier manufactured by Micro Commercial Components (MCC). It features an average forward current of 350 mA and a maximum repetitive peak reverse voltage of 40 V. The device utilizes silicon technology in a surface-mount SOD-123 package. Key electrical parameters include a forward voltage of 600 mV at 200 mA, a reverse leakage current of 5 µA at 30 V, and a reverse recovery time of 10 ns. Operating temperatures range from -55°C to +125°C junction temperature.

Single Diodes Feature Summary

• Schottky barrier construction for low forward voltage drop
• Silicon planar dielectric isolation structure
• Surface-mount SOD-123 packaging for automated assembly

Single Diodes Applications

• High-frequency rectification in DC-DC converters
• Reverse polarity protection circuits
• Clamping diodes in switching applications

Single Diodes Procurement Notes

Verify the specific suffix against official MCC documentation to confirm exact electrical tolerances and marking codes. Confirm RoHS compliance status and REACH SVHC declarations with the manufacturer prior to integration. Ensure the ordering code matches the required package variant and lead-free specifications for your manufacturing process.

Single Diodes Selection Notes

Select this component for designs requiring low forward voltage and fast switching characteristics in compact surface-mount layouts. Compare the 40 V rating and 350 mA current capacity against circuit requirements. Consider thermal management needs given the small SOD-123 footprint and specified operating temperature range.

Single Diodes Part Context

This part belongs to the SD103 series of Schottky diodes from Micro Commercial Components. The series offers various voltage ratings and current options within the SOD-123 form factor. The SD103C-TP specifically addresses applications needing 40 V blocking capability with efficient high-speed rectification properties.

Single Diodes Replacement Considerations

SD103AWS-TP is listed as a verified substitute for related discontinued parts in the MBRX series. Verify pinout compatibility and electrical parameter equivalence before substitution.
