SDCL0603Q1N6BT02B03

$0.01

Description：FIXED IND 1.6NH 600MA 130MOHM SM
Series：SDCL0603Q-02-B
Mfr：Shenzhen Sunlord Electronics Co., Ltd.
Package：Tape & Reel (TR)

SKU:33ea4082e838 Category: Fixed Inductors Brand: Shenzhen Sunlord Electronics Co., Ltd.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SDCL0603Q1N6BT02B03 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Shenzhen Sunlord Electronics Co., Ltd.. Its product description is FIXED IND 1.6NH 600MA 130MOHM SM. Review the specifications below when checking this part for your BOM.

Fixed Inductors specifications for SDCL0603Q1N6BT02B03

Description：FIXED IND 1.6NH 600MA 130MOHM SM
Series：SDCL0603Q-02-B
Mfr：Shenzhen Sunlord Electronics Co., Ltd.
Package：Tape & Reel (TR)
Type：Multilayer
Material - Core：Ceramic
Inductance：1.6 nH
Tolerance：±0.1nH
Current Rating (Amps)：600 mA
Current - Saturation (Isat)：-
Shielding：Unshielded
DC Resistance (DCR)：130mOhm Max
Q @ Freq：13 @ 500MHz
Frequency - Self Resonant：15GHz
Ratings：-
Operating Temperature：-55°C ~ 125°C
Inductance Frequency - Test：500 MHz
Mounting Type：Surface Mount
Package / Case：0201 (0603 Metric)
Supplier Device Package：201
Size / Dimension：0.024" L x 0.012" W (0.60mm x 0.30mm)
Height - Seated (Max)：0.013" (0.33mm)
Features：-

Fixed Inductors datasheet and documents for SDCL0603Q1N6BT02B03

SDCL0603Q1N6BT02B03

Fixed Inductors Overview

The SDCL0603Q1N6BT02B03 is a fixed multilayer inductor manufactured by Shenzhen Sunlord Electronics Co., Ltd. It features a 0201 (0603 metric) surface-mount package with dimensions of 0.60mm x 0.30mm and a height of 0.30mm. The component has an inductance of 1.6nH, a tolerance of ±0.3nH, and a rated current of 600mA. Its maximum DC resistance is 130mΩ, and it operates within a temperature range of -55°C to +125°C.

Fixed Inductors Feature Summary

Multilayer ceramic construction for high reliability
Optimized for high-frequency applications
Surface-mount design suitable for automated assembly

Fixed Inductors Applications

RF circuits
Impedance matching networks
High-frequency filtering

Fixed Inductors Procurement Notes

Verify the specific ordering suffix against official Sunlord documentation to confirm exact electrical tolerances and packaging specifications. Ensure that the procurement channel provides authentic components from Shenzhen Sunlord Electronics Co., Ltd. to guarantee performance consistency and supply chain integrity.

Fixed Inductors Selection Notes

Select this component for designs requiring ultra-low inductance values in minimal footprint spaces. The 0201 package size supports dense PCB layouts, while the 600mA current rating suits low-power RF signal paths. Evaluate thermal constraints to ensure operation remains within the specified -55°C to +125°C range during deployment.

Fixed Inductors Part Context

This part belongs to the SDCL0603Q series of unshielded multilayer inductors produced by Sunlord. The series targets high-frequency electronic applications where small form factors are critical. Sunlord specializes in magnetic devices, microwave components, and sensitive elements for communications and consumer electronics markets.
