SDCL1005C7N5HTDF

Fixed Inductors Overview

The SDCL1005C7N5HTDF is a fixed surface-mount inductor manufactured by Shenzhen Sunlord Electronics Co., Ltd. It belongs to the SDCL-D series and utilizes a 0402 (1005 metric) package with dimensions of 1.00 x 0.50 mm and a height of 0.50 mm. The component features an inductance value of 7.5 nH with a tolerance of ±25%. It has a self-resonant frequency of 3.5 GHz and a rated current of 100 mA. The DC resistance is specified at 0.06 ohms, and it operates within a temperature range of -55°C to +125°C.

Fixed Inductors Feature Summary

• Ultra-low inductance design suitable for high-frequency applications
• Compact 0402 surface-mount footprint for space-constrained layouts
• High self-resonant frequency capability up to 3.5 GHz

Fixed Inductors Applications

• RF matching networks
• Impedance matching circuits
• High-frequency signal filtering

Fixed Inductors Procurement Notes

Verify the specific suffix HTDF against official datasheets to confirm packaging details and tape/reel specifications. Ensure compatibility with standard SMT assembly processes for 0402 components. Cross-reference the manufacturer's latest documentation for any updates on RoHS compliance or material composition before finalizing procurement orders.

Fixed Inductors Selection Notes

Select this component when ultra-low inductance values are required for RF circuit tuning. The 0402 package size supports dense PCB layouts. Consider the 100 mA rated current and low DC resistance for power efficiency. Verify that the 3.5 GHz self-resonant frequency aligns with the target operating frequency of the application circuit.

Fixed Inductors Part Context

This part is produced by Shenzhen Sunlord Electronics Co., Ltd., a manufacturer specializing in chip electronic components including magnetic devices, microwave devices, and sensitive devices. The company serves various sectors such as communications, consumer electronics, automotive electronics, and industrial electronics. The SDCL series represents their line of fixed surface-mount inductors designed for high-frequency performance.

Fixed Inductors Replacement Considerations

Consult official substitution lists from Shenzhen Sunlord Electronics Co., Ltd. for verified equivalent parts. Generic replacements may not match the precise 7.5 nH inductance or 3.5 GHz self-resonant frequency requirements.
