SDMM0806U-2-350TB01

Overview

The SDMM0806U-2-350TB01 is a two-line common mode choke manufactured by Shenzhen Sunlord Electronics Co., Ltd. in an 0806 surface mount package. It exhibits an impedance of 35 Ohms at 100 MHz and supports a current rating of 100 mA. The direct current resistance (DCR) is specified as 3.5 Ohms, with a maximum height of 0.45 mm.

Feature Summary

• Provides signal line filtering for differential data lines
• Designed for high-speed interface applications requiring noise suppression

Applications

• MIPI interfaces in mobile devices
• MHL connections
• HDMI signal protection

Procurement Notes

Verify the specific suffix TB01 against official Sunlord documentation to confirm exact packaging or variant specifications. Ensure the component matches the required 0806 footprint and electrical parameters for your design. Cross-reference datasheets from authorized distributors to validate authenticity and technical compliance before procurement.

Selection Notes

Select this component for applications requiring compact filtering on high-speed differential pairs. The 0806 package size suits space-constrained designs. Verify that the 100 mA current rating meets the operational requirements of the target circuit to ensure reliable performance without saturation.

Part Context

This part belongs to the SDMM series of stacked common mode chokes from Sunlord. These components are engineered for portable electronics and consumer devices where small form factors and effective electromagnetic interference suppression are critical for maintaining signal integrity in high-speed data transmission lines.

Replacement Considerations

Consult official Sunlord substitution guides for compatible alternatives. Verify pin compatibility and electrical characteristics such as impedance and current ratings when considering cross-brand replacements.
