SDRH0830NT100 is listed in the Fixed Inductors range at ChipApex. The manufacturer field lists Viking Tech. Its product description is FIXED IND 10UH 2.5A 47 MOHM SMD. Review the specifications below when checking this part for your BOM.
Fixed Inductors specifications for SDRH0830NT100
- Description：FIXED IND 10UH 2.5A 47 MOHM SMD
- Series：SDRH
- Mfr：Viking Tech
- Package：Tape & Reel (TR)
- Type：-
- Material - Core：-
- Inductance：10 µH
- Tolerance：±30%
- Current Rating (Amps)：2.5 A
- Current - Saturation (Isat)：-
- Shielding：Shielded
- DC Resistance (DCR)：47mOhm Max
- Q @ Freq：-
- Frequency - Self Resonant：-
- Ratings：-
- Operating Temperature：-40°C ~ 125°C
- Inductance Frequency - Test：100 kHz
- Mounting Type：Surface Mount
- Package / Case：Nonstandard
- Supplier Device Package：-
- Size / Dimension：0.315" L x 0.315" W (8.00mm x 8.00mm)
- Height - Seated (Max)：0.118" (3.00mm)
- Features：-
Fixed Inductors datasheet and documents for SDRH0830NT100
Fixed Inductors Overview
The SDRH0830NT100 is a fixed surface-mount inductor manufactured by Viking Tech. It features a nominal inductance of 10 microhenries (10uH) and supports a maximum current rating of 2.5 amperes. The component exhibits a direct current resistance (DCR) of 47 milliohms. Designed for compact electronic assemblies, it utilizes a shielded structure to minimize electromagnetic interference. The device is compliant with RoHS standards and is intended for high-density circuit board applications requiring reliable magnetic performance.
Fixed Inductors Feature Summary
- Shielded construction reduces electromagnetic interference
- Supports high current operation up to 2.5A
- Low DC resistance for efficient power delivery
Fixed Inductors Applications
- Power supply filtering circuits
- DC-DC converter energy storage
- Signal processing choke coils
Fixed Inductors Procurement Notes
Verify the specific manufacturer part number against official Viking Tech documentation to confirm electrical characteristics and physical dimensions. Ensure compliance with relevant environmental directives such as RoHS before integration into final products. Cross-reference datasheet specifications for thermal management requirements during procurement planning.
Fixed Inductors Selection Notes
Select this component based on the required inductance value of 10uH and the current handling capability of 2.5A. Evaluate the low DCR specification for efficiency needs in power paths. Confirm that the surface-mount package dimensions fit within the available PCB real estate constraints for the target design.
Fixed Inductors Part Context
This component belongs to the SDRH series of shielded surface-mount inductors produced by Viking Tech. The series is engineered for applications demanding stable inductance values under varying load conditions. The specific model integrates a metal alloy powder core to provide robust performance in space-constrained environments.
Fixed Inductors Replacement Considerations
Consult official Viking Tech catalogs or authorized distributor databases for verified substitute part numbers. Ensure any replacement matches the 10uH inductance, 2.5A current rating, and 47mohm DCR specifications while maintaining compatible physical footprint.
