Product Detailed Parameters
- Description：SAW FILTER SMD 13.3X6.5X1.8,70.0
- Series：SF1365
- Mfr：Suzhou Hangjing Elec&Tech Co.,Ltd
- Package：Tape & Reel (TR),Strip
- Frequency - Center：70MHz
- Bandwidth：2MHz
- Insertion Loss：9.2dB
- Ratings：-
- Applications：-
- Mounting Type：Surface Mount
- Package / Case：-
- Height (Max)：0.071" (1.80mm)
- Size / Dimension：0.524" L x 0.256" W (13.30mm x 6.50mm)
Download product information
Overview
The SF1365-70.000-F02IL11AG is a Surface Acoustic Wave (SAW) filter manufactured by Suzhou Hangjing Elec&Tech Co., Ltd. It operates at a center frequency of 70.000 MHz with a bandwidth of 2 MHz. The device exhibits an insertion loss of 9.2 dB and is designed for surface-mount technology applications. Its physical dimensions are specified as 13.3 mm in length, 6.5 mm in width, and 1.8 mm in height.
Feature Summary
- Utilizes Surface Acoustic Wave technology for frequency-selective signal processing
- Engineered for surface-mount integration into electronic assemblies
- Provides defined bandwidth characteristics for RF signal filtering
Applications
- RF signal filtering in communication systems
- Frequency selection in quartz frequency control units
- Integration into piezoelectric ceramic-based electronic devices
Procurement Notes
Verify the manufacturer designation matches Suzhou Hangjing Elec&Tech Co., Ltd. Confirm the part number includes the full suffix F02IL11AG to ensure correct specifications. Check datasheets for precise mechanical tolerances and electrical performance curves before integration. Ensure compatibility with surface-mount assembly processes.
Selection Notes
Select this component when a 70 MHz SAW filter with 2 MHz bandwidth is required. Consider the 9.2 dB insertion loss impact on system gain. Verify that the 13.3x6.5x1.8 mm package fits the PCB layout constraints. Compare against other SAW filters if lower insertion loss or different bandwidths are needed.
Part Context
Suzhou Hangjing Elec&Tech Co., Ltd specializes in quartz frequency control components and piezoelectric ceramic filters. This SAW filter belongs to their range of frequency-selective devices used in RF applications. The company focuses on research, development, and production of these electronic components.
FAQ
What is the center frequency of the SF1365-70.000-F02IL11AG?
The center frequency is 70.000 MHz.
What is the physical package size of this SAW filter?
The package dimensions are 13.3 mm x 6.5 mm x 1.8 mm.
