SG-8003LB MPL0 2.5V

Overview

The SG-8003LB MPL0 2.5V is a programmable crystal oscillator (XO) manufactured by Epson, operating at a supply voltage of 2.5V. It features a CMOS output interface and supports a frequency range from 1MHz to 166MHz with a stability of 50PPM. The device draws a maximum supply current of 15mA and consumes up to 50µA in disable mode. It is RoHS3 compliant and designed for high-performance timing applications requiring precise clock signals.

Feature Summary

• Programmable frequency generation within a wide range
• Low power consumption with dedicated disable mode
• CMOS output compatibility for digital circuits

Applications

• High-speed data communication systems
• Network infrastructure equipment
• Consumer electronics requiring precise timing

Procurement Notes

Verify the specific frequency configuration and package type against the official datasheet before ordering. Ensure the 2.5V supply requirement aligns with the target circuit design. Confirm RoHS3 compliance status if environmental regulations are critical for the application.

Selection Notes

Select this component when a programmable solution with low power usage is required. Consider the 15mA max current draw for power budgeting. The 50PPM stability suits general-purpose timing needs rather than ultra-high precision references.

Part Context

This part belongs to the SG-8003LB series of programmable oscillators from Epson. The series offers flexibility in frequency selection while maintaining compact form factors suitable for modern electronic designs.

Replacement Considerations

Check Epson's official substitution list for compatible alternatives. Verify pinout and electrical specifications match before replacing.
