SG2016CAN 50.0000M-TJGA0

Oscillators Overview

The SG2016CAN 50.0000M-TJGA0 is a Simple Packaged Crystal Oscillator (SPXO) manufactured by EPSON, featuring a CMOS output signal. It operates at a nominal frequency of 50 MHz with a standard frequency stability of ±50 ppm. The device supports a supply voltage range of 1.8V to 3.3V and includes a standby function for power-down control. It utilizes a crystal as the basic resonator and is housed in a compact 4-SMD, No Lead package with dimensions of 2.0mm x 1.6mm. The component is designed for surface mount installation and offers low current consumption during operation.

Oscillators Feature Summary

• CMOS output signal compatible with digital logic interfaces
• Integrated standby function for power management
• Compact surface-mount package design for space-constrained applications

Oscillators Applications

• Automotive multimedia systems
• Body electronics and remote control devices
• Security and surveillance equipment

Oscillators Procurement Notes

Verify the specific suffix codes against the official datasheet to ensure correct frequency, tolerance, and packaging options. Confirm that the selected variant matches the required operating temperature range and supply voltage specifications for the target application environment before finalizing procurement orders.

Oscillators Selection Notes

Select this model when a 50 MHz clock source is required within the SG2016CAN series footprint. Ensure the system design accommodates the 1.8V to 3.3V supply range and utilizes the CMOS output characteristics. Consider the ±50 ppm stability requirement relative to the system's timing accuracy needs.

Oscillators Part Context

This component belongs to the SG2016CAN series of Simple Packaged Crystal Oscillators from EPSON Timing. The series provides various standard frequencies ranging from 4 MHz to 72 MHz, all featuring CMOS outputs and low-power standby capabilities within a small 2016 package format suitable for portable and automotive electronics.

Oscillators Replacement Considerations

Public confirmed substitute part numbers are not available in the provided documentation. Consult official EPSON distributors or technical support for cross-reference information regarding equivalent oscillators with matching electrical and mechanical specifications.
