SH150C-3.00-38

Fixed Inductors Overview

The SH150C-3.00-38 is a fixed inductor from the SH150 series manufactured by Amgis, LLC. It features a toroidal core made of iron powder material with an inductance of 38 µH and a tolerance of ±20%. The component is rated for a current of 3 A and has a DC resistance of 50 mΩ. Designed for surface mount applications, it operates within a temperature range of -40°C to 125°C. The unit is unshielded and tested at a frequency of 10 kHz.

Fixed Inductors Feature Summary

• Utilizes iron powder toroidal core construction for stable magnetic performance
• Provides high current handling capability of 3 A with low DC resistance
• Features unshielded design suitable for various mounting configurations

Fixed Inductors Applications

• Power supply filtering circuits
• DC-DC converter input/output stages
• General electronic signal conditioning

Fixed Inductors Procurement Notes

Verify the specific package variant when ordering, as the SH150 series includes both surface mount (S) and through-hole (C) versions. Confirm that the C suffix corresponds to the radial vertical open configuration required for your assembly process. Cross-reference manufacturer datasheets to ensure compatibility with existing board layouts and thermal management requirements before finalizing procurement.

Fixed Inductors Selection Notes

Select this component for applications requiring robust current handling and moderate inductance values. The iron powder core offers superior saturation characteristics compared to ferrite alternatives. Ensure the selected variant matches the intended mounting method, as surface mount and through-hole versions share similar electrical parameters but differ physically. Verify space constraints against the specified dimensions.

Fixed Inductors Part Context

This part belongs to the SH150 series of fixed inductors produced by Amgis, LLC. The series encompasses various inductance and current ratings tailored for power electronics. The SH150C-3.00-38 specifically addresses needs for higher current applications where compact size and reliable performance are critical. It serves as a direct replacement for obsolete parts like the SWC-3.00-38.

Fixed Inductors Replacement Considerations

The SH150C-3.00-38 is listed as a direct substitute for the obsolete SWC-3.00-38. When replacing discontinued components, verify mechanical fit and electrical equivalence. Ensure the new part meets all original design specifications regarding current rating and inductance tolerance.
