SI5350A-B05941-GMR

Clock Generators, PLLs, Frequency Synthesizers Overview

The SI5350A-B05941-GMR is a factory-programmable CMOS clock generator manufactured by Skyworks Solutions. It utilizes a PLL and MultiSynth architecture to generate up to eight non-integer-related frequencies ranging from 2.5 kHz to 200 MHz with 0 ppm error. The device operates on a single supply voltage of 1.8 V, 2.5 V, or 3.3 V for both core and output buffers. It features low period jitter typically below 70 ps pp and supports configurable spread spectrum modulation. The component is housed in a 20-QFN package and requires a 25 MHz or 27 MHz crystal reference.

Clock Generators, PLLs, Frequency Synthesizers Feature Summary

• Generates multiple independent clock frequencies from a single crystal reference
• Supports glitchless frequency changes via programmable control pins
• Configurable spread spectrum functionality to reduce electromagnetic interference
• Provides separate voltage supplies for core logic and output buffers

Clock Generators, PLLs, Frequency Synthesizers Applications

• HDTV and Blu-ray player systems
• Set-top boxes and residential gateways
• Servers and storage equipment
• Networking and communication infrastructure

Clock Generators, PLLs, Frequency Synthesizers Procurement Notes

Verify the specific factory programming configuration associated with the B05941 suffix using ClockBuilder Pro software. Confirm that the required output frequencies and control pin mappings match the design requirements before procurement. Ensure the ordering suffix corresponds to the correct tape and reel packaging format.

Clock Generators, PLLs, Frequency Synthesizers Selection Notes

Select this component when a cost-effective replacement for multiple discrete crystals and oscillators is required. Choose the 20-QFN package variant if eight independent outputs are necessary. Verify that the target application can accommodate the specified power supply voltages and crystal load capacitance requirements.

Clock Generators, PLLs, Frequency Synthesizers Part Context

This part belongs to the Si5350 family of factory-programmable clock generators. It serves as a flexible alternative to fixed-frequency oscillators, allowing designers to customize output frequencies without changing hardware components. The device integrates high-resolution fractional dividers to achieve precise frequency synthesis across a wide range of applications.

Clock Generators, PLLs, Frequency Synthesizers Replacement Considerations

Direct replacements include other factory-programmed variants within the Si5350A series, such as SI5350A-Bxxxxx-GMR. Ensure substitute parts maintain the same 20-QFN package outline and electrical characteristics. Verify that the new part number contains the necessary frequency configuration for the specific application.
