SKMW40G-15

$45.23

Description：40W;18-75VIN; 15VOUT @2667MA,1"*
Series：SKMW40
Mfr：MEAN WELL USA Inc.
Package：Bulk

SKU:879fae63f9db Category: Voltage Regulators - DC DC Switching Regulators Brand: MEAN WELL USA Inc.

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SKMW40G-15 is listed in the Voltage Regulators - DC DC Switching Regulators range at ChipApex. The manufacturer field lists MEAN WELL USA Inc.. Its product description is 40W;18-75VIN; 15VOUT @2667MA,1"*. Review the specifications below when checking this part for your BOM.

Voltage Regulators - DC DC Switching Regulators specifications for SKMW40G-15

Description：40W;18-75VIN; 15VOUT @2667MA,1"*
Series：SKMW40
Mfr：MEAN WELL USA Inc.
Package：Bulk
Function：-
Output Configuration：Positive
Topology：-
Output Type：Fixed
Number of Outputs：1
Voltage - Input (Min)：18V
Voltage - Input (Max)：75V
Voltage - Output (Min/Fixed)：15V
Voltage - Output (Max)：-
Current - Output：2.667A
Frequency - Switching：400kHz
Synchronous Rectifier：No
Operating Temperature：-40°C ~ 80°C
Mounting Type：Through Hole
Package / Case：6-DIP Module
Supplier Device Package：-
Grade：-
Qualification：-

Voltage Regulators - DC DC Switching Regulators datasheet and documents for SKMW40G-15

SKMW40G-15

Voltage Regulators - DC DC Switching Regulators Overview

The SKMW40G-15 is a 40W isolated DC/DC converter from the MEAN WELL SKMW40 series, designed for through-hole mounting. It features an input voltage range of 18V to 75V and provides a regulated 15V output at a maximum current of 2.67A. The unit measures 25.4mm x 25.4mm x 10mm and operates within a temperature range of -40°C to +85°C.

Voltage Regulators - DC DC Switching Regulators Feature Summary

Provides high-density power conversion in a compact 1x1 inch DIP package suitable for space-constrained designs.
Features wide input voltage capability to accommodate varying supply conditions across industrial applications.
Offers galvanic isolation to ensure safety and signal integrity between input and output circuits.

Voltage Regulators - DC DC Switching Regulators Applications

Industrial automation control systems
Telecommunications equipment power distribution
Medical device internal power modules

Voltage Regulators - DC DC Switching Regulators Procurement Notes

Verify the specific suffix against the official datasheet to confirm output voltage and current ratings. Ensure the ordering code matches the required DIP pin configuration and regulatory certifications for your target market. Cross-reference the manufacturer's latest documentation to confirm component availability and lifecycle status before finalizing procurement plans.

Voltage Regulators - DC DC Switching Regulators Selection Notes

Select this component when a 40W isolated solution with a wide 18-75V input range is required. The 1x1 inch footprint allows for efficient board layout compared to larger converters. Consider the thermal performance requirements relative to the 85°C maximum operating temperature limit during system integration.

Voltage Regulators - DC DC Switching Regulators Part Context

This part belongs to the SKMW40 series, which offers various output voltages within the same physical form factor. The series is characterized by its through-hole construction and robust isolation capabilities, targeting reliable performance in demanding environments where standard surface-mount options may be insufficient.

Voltage Regulators - DC DC Switching Regulators Replacement Considerations

Consult the official MEAN WELL replacement guide for verified substitutes. Ensure any alternative maintains the same 1x1 inch DIP footprint and 40W power rating to fit existing mechanical constraints without redesigning the PCB.
