SL 11 112 12 S

$0.68

Description：ONE ROW, 0.635 MM
Series：SL 11 112
Mfr：Fischer Elektronik
Package：-

SKU:89cbec1666dd Category: Headers, Male Pins Brand: Fischer Elektronik

Consult the customer manager about the wholesale price.

consultation hotline：86-132-6715-2157

email：[email protected]
Contact the product manager for consultation. One-stop consultation is available.

Do you want a lower wholesale price? Please send us your inquiry and we will reply immediately.

Product introduction

SL 11 112 12 S is listed in the Headers, Male Pins range at ChipApex. The manufacturer field lists Fischer Elektronik. Its product description is ONE ROW, 0.635 MM. Review the specifications below when checking this part for your BOM.

Headers, Male Pins specifications for SL 11 112 12 S

Description：ONE ROW, 0.635 MM
Series：SL 11 112
Mfr：Fischer Elektronik
Package：-
Connector Type：Header
Contact Type：Male Pin
Pitch - Mating：0.100" (2.54mm)
Number of Positions：12
Number of Rows：1
Row Spacing - Mating：-
Number of Positions Loaded：All
Style：Board to Board or Cable
Shrouding：Unshrouded
Mounting Type：Through Hole
Termination：Solder
Fastening Type：Push-Pull
Contact Length - Mating：0.213" (5.40mm)
Contact Length - Post：0.118" (3.00mm)
Overall Contact Length：0.441" (11.20mm)
Insulation Height：0.110" (2.80mm)
Contact Shape：Square
Contact Finish - Mating：Gold
Contact Finish Thickness - Mating：157.5µin (4.00µm)
Contact Finish - Post：Tin
Contact Material：Copper Tin
Insulation Material：Polyamide (PA46), Nylon 4/6, Glass Filled
Features：-
Operating Temperature：-40°C ~ 163°C
Material Flammability Rating：UL94 V-0
Insulation Color：Black
Current Rating (Amps)：3A
Voltage Rating：250VAC

Headers, Male Pins datasheet and documents for SL 11 112 12 S

SL 11 112 12 S

Headers, Male Pins Overview

The SL 11 112 12 S is a single-row male pin header connector manufactured by Fischer Elektronik. It features a 0.100-inch (2.54 mm) pitch and contains 12 positions. The contact material is copper-tin, with a tin plating thickness of 157.5 µin (4.00 µm). The total contact length measures 0.441 inches (11.20 mm), comprising a mating length of 0.213 inches (5.40 mm) and a column length of 0.118 inches (3.00 mm). The insulating height is 0.110 inches (2.80 mm). The connector utilizes square contacts and is designed for through-hole mounting.

Headers, Male Pins Feature Summary

Single-row configuration with square-shaped male pins
Through-hole termination method for PCB integration
Tin-plated copper-tin contact material for conductivity

Headers, Male Pins Applications

General-purpose PCB interconnection
Signal routing in electronic assemblies
Prototype board connections

Headers, Male Pins Procurement Notes

Verify the specific suffix 'S' against the manufacturer's datasheet to confirm tin plating specifications. Ensure the 12-position count matches the design requirement. Check for RoHS compliance status if required by the assembly process. Confirm that the through-hole footprint aligns with the PCB layout guidelines provided in the official documentation.

Headers, Male Pins Selection Notes

Select this component when a single-row, 2.54 mm pitch header with 12 positions is required. The tin-plated contacts are suitable for standard soldering processes. Consider the 11.20 mm total height for clearance constraints. This part is appropriate for applications requiring robust mechanical retention via through-hole technology.

Headers, Male Pins Part Context

This component belongs to the SL 11 series of PCB connectors from Fischer Elektronik. The series offers various position counts and plating options. The SL 11 112 12 S specifically denotes a 12-position variant within this standardized line of male headers designed for reliable electrical connections on printed circuit boards.
