SL 11 112 14 Z

Headers, Male Pins Overview

The SL 11 112 14 Z is a male pin header connector manufactured by Fischer Elektronik. It features a single row configuration with 14 contacts and a 0.100-inch (2.54 mm) pitch. The component utilizes through-hole termination for PCB mounting. Contact surfaces are tin-plated, providing reliable electrical connectivity. The housing is black, constructed from polyamide material to ensure mechanical stability and insulation. This straight orientation header is designed for secure board-to-board or cable connections in electronic assemblies.

Headers, Male Pins Feature Summary

• Single-row male pin header design for standard interconnect applications
• Tin-plated contact surfaces for corrosion resistance and conductivity
• Through-hole termination method ensures robust mechanical fixation
• Polyamide housing provides structural integrity and electrical insulation

Headers, Male Pins Applications

• General-purpose electronic circuit board interconnections
• Industrial control panel wiring harnesses
• Consumer electronics assembly modules
• Prototype development and testing setups

Headers, Male Pins Procurement Notes

Verify the specific part number SL 11 112 14 Z against official Fischer Elektronik documentation to confirm contact count and plating specifications. Ensure compatibility with mating connectors regarding pitch and row configuration. Check for any RoHS compliance requirements relevant to your manufacturing process. Confirm that the through-hole footprint matches your PCB design guidelines before procurement.

Headers, Male Pins Selection Notes

Select this component when a single-row, 14-position male header is required for through-hole mounting. The 2.54 mm pitch is standard for many commercial and industrial applications. Tin plating offers a cost-effective solution for general use, while the black polyamide housing provides visual contrast and durability. Consider current carrying capacity and voltage ratings based on specific application loads.

Headers, Male Pins Part Context

The SL 11 112 series represents Fischer Elektronik's line of precision-engineered male headers. These components are designed for high-density interconnects in various electronic environments. The SL 11 112 14 Z specifically denotes a 14-contact variant within this family, maintaining consistent dimensional standards across the series for interchangeability and ease of integration into existing designs.

Headers, Male Pins Replacement Considerations

Direct substitutes may include other manufacturers' 14-pin, 2.54 mm pitch male headers with tin plating. Verify mechanical dimensions, including overall height and pin length, to ensure fit within the enclosure. Electrical characteristics such as nominal current and voltage must match or exceed original specifications. Cross-reference with Fischer Elektronik's official alternative recommendations if available.
