SL 11 124 14 Z

Headers, Male Pins Overview

The SL 11 124 14 Z is a single-row pin header connector manufactured by Fischer Elektronik. It features a 0.635 mm (0.025 inch) pitch and contains 14 positions. The connector utilizes tin-plated contacts with a rated voltage of 250 V and a nominal current of 3 A. Designed for through-hole mounting, it belongs to the SL 11 124 series and is intended for board-to-board or wire-to-board interconnections.

Headers, Male Pins Feature Summary

• Single-row configuration with 0.635 mm precision pitch
• Tin-plated contact surfaces for reliable conductivity
• Through-hole mounting style for PCB integration

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• General electronic assembly requiring compact spacing

Headers, Male Pins Procurement Notes

Verify the specific part number against official Fischer Elektronik documentation to confirm the 0.635 mm pitch variant. Ensure the tin-plated finish matches application requirements. Cross-reference the 14-position count and through-hole termination type with design specifications before procurement.

Headers, Male Pins Selection Notes

Select this component when a compact 0.635 mm pitch is required rather than standard 2.54 mm spacing. Confirm that the 3 A current rating and 250 V voltage limit suit the circuit load. Validate that the single-row format fits the available PCB footprint constraints.

Headers, Male Pins Part Context

This part belongs to the Fischer Elektronik SL 11 124 series, which specializes in high-density connectors. Unlike standard 2.54 mm headers, this series offers tighter 0.635 mm spacing for space-constrained designs. The SL 11 124 14 Z represents a specific position count within this specialized lineup.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 0.635 mm pitch and 14-position count. Generic 2.54 mm headers are not compatible due to significant spacing differences. Verify mechanical dimensions and contact plating compatibility with existing mating components.
