SL 11 124 24 S

Headers, Male Pins Overview

The SL 11 124 24 S is a board connector manufactured by Fischer Elektronik. It features 24 contacts arranged in two rows with a male configuration and straight solder terminals. The component utilizes a 2.54 mm contact pitch and includes gold-plated mating and termination surfaces. Designed for general-purpose applications, it complies with RoHS standards and is lead-free.

Headers, Male Pins Feature Summary

• Dual-row male header design for vertical board mounting
• Gold-plated contact surfaces for reliable signal transmission
• Standard 2.54 mm pitch spacing for broad compatibility

Headers, Male Pins Applications

• General-purpose electronic circuit interconnections
• Industrial control system board-to-board connections
• Consumer electronics assembly modules

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the manufacturer's current datasheet to ensure exact pin count and row configuration match the design requirements. Confirm that the gold plating specification aligns with the intended electrical environment. Check for RoHS compliance documentation if required by project regulations before finalizing procurement.

Headers, Male Pins Selection Notes

Select this component when a dual-row male header with gold contacts is required for standard 2.54 mm pitch applications. Ensure the straight solder terminal style matches the PCB layout constraints. Consider the general-purpose classification for non-critical signal paths where high-frequency performance is not the primary driver.

Headers, Male Pins Part Context

This part belongs to the Fischer Elektronik SL series of board connectors. The series offers various contact counts and configurations for standard industrial and commercial electronics. The SL 11 124 24 S specifically addresses needs for compact, reliable interconnects in space-constrained assemblies requiring durable gold-plated contacts.

Headers, Male Pins Replacement Considerations

Direct substitutes within the same Fischer Elektronik SL series should be evaluated based on identical contact count (24), row configuration (2), and pitch (2.54 mm). Verify mechanical footprint compatibility and terminal plating specifications before substitution.
