SL 11 139 30 S

Headers, Male Pins Overview

The SL 11 139 30 S is a single-row male pin header connector manufactured by Fischer Elektronik. It features 30 positions with a 2.54 mm (0.100 inch) pitch, designed for through-hole mounting on printed circuit boards. The contacts are constructed from copper alloy and finished with tin plating to ensure reliable electrical connections. Rated for 250 VAC and 3 A, the connector operates within a temperature range of -40°C to +163°C. The housing is made of black PA46 nylon reinforced with glass fiber, meeting UL94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Through-hole mounting style suitable for board-to-board or wire-to-board applications
• Tin-plated square male pins for secure mating interface
• Glass-fiber reinforced polyamide insulation for thermal stability

Headers, Male Pins Applications

• Industrial control panel interconnections
• Consumer electronics assembly
• General-purpose PCB signal routing

Headers, Male Pins Procurement Notes

Verify the specific contact count matches the '30' designation in the model number. Confirm that the through-hole termination type aligns with the target PCB fabrication capabilities. Ensure the operating voltage and current ratings meet the system requirements. Check for RoHS compliance status if required by project specifications. Validate the insulation material properties against environmental conditions.

Headers, Male Pins Selection Notes

Choose this component when a standard 2.54 mm pitch male header is required for permanent board connections. The through-hole design offers mechanical stability compared to surface-mount alternatives. Consider the 30-position length for space constraints on the layout. The tin finish provides cost-effective conductivity without gold plating costs. Verify compatibility with mating female sockets from the same series.

Headers, Male Pins Part Context

This part belongs to the SL 11 139 series of Fischer Elektronik headers. The series offers various contact counts and mounting options. Similar parts include the SL 11 139 33 Z and SL 11 139 30 G, differing in position count or plating. The series is designed for general electronic interconnect needs.

Headers, Male Pins Replacement Considerations

Direct substitutes may include SL 11 139 30 G if gold plating is acceptable. Other Fischer Elektronik headers with identical pitch and position count can serve as functional replacements. Verify mechanical dimensions before swapping with non-Fischer brands.
