SL 11 164 17 G

Headers, Male Pins Overview

The SL 11 164 17 G is a pin header connector manufactured by Fischer Elektronik. It features a single row of 17 contacts with a 2.54 mm (0.100 inch) pitch. The component utilizes through-hole termination and includes gold-plated contacts for reliable signal transmission. The insulating body is constructed from PA 4.6 GF material, ensuring stability across an operating temperature range of -40°C to +163°C. The connector supports a nominal voltage of 250 V AC and a nominal current of 3 A, with a test voltage rating of 2000 V.

Headers, Male Pins Feature Summary

• Single-row pin header design with 17 positions
• Gold-plated contact surfaces for enhanced conductivity
• Through-hole mounting for secure PCB attachment
• High-temperature resistant PA 4.6 GF insulating body

Headers, Male Pins Applications

• General electronic interconnects
• Industrial control systems
• Consumer electronics assemblies

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix 'G' corresponds to the required gold plating thickness and contact configuration as defined in the official datasheet. Confirm that the 17-position count matches the design requirements. Ensure compatibility with mating connectors regarding pitch and height specifications before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when a single-row, 17-pin through-hole header is required. The gold plating offers superior corrosion resistance compared to tin variants. Verify that the 2.54 mm pitch aligns with the board layout. Consider the thermal stability of the PA 4.6 GF material for high-temperature soldering processes or operational environments.

Headers, Male Pins Part Context

This part belongs to the SL 11 series of pin headers from Fischer Elektronik. The series offers various contact counts and plating options. The SL 11 164 17 G specifically denotes a 17-position variant with gold contacts. This series is designed for standard rectangular connector applications requiring robust mechanical and electrical performance.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 17-position count, 2.54 mm pitch, and gold plating specification. Cross-reference with other manufacturers offering equivalent through-hole pin headers. Ensure the replacement maintains the same insulating material properties and current/voltage ratings.
