SL 11 164 4 S

Headers, Male Pins Overview

The SL 11 164 4 S is a surface mount male pin header manufactured by Fischer Elektronik. It features a 2-row configuration with 4 positions and a 0.100 inch (2.54 mm) contact spacing. The connector utilizes gold-plated contacts for the mating interface and tin-plated posts, constructed from copper-tin material. Insulation is provided by glass-filled polyamide (PA46), rated UL94 V-0. The assembly supports an operating temperature range of -40°C to 163°C and includes a push-pull locking mechanism.

Headers, Male Pins Feature Summary

• Surface mount design for automated PCB assembly
• Push-pull locking mechanism for secure connection
• Gold-plated mating contacts for reliable signal transmission
• Glass-filled polyamide insulation with UL94 V-0 rating

Headers, Male Pins Applications

• High-density electronic circuit boards
• Industrial control systems requiring robust interconnects
• Automotive electronics modules
• Communication equipment interfaces

Headers, Male Pins Procurement Notes

Verify that the specific suffix 'S' denotes the surface mount variant as required by your PCB layout. Confirm that the 4-position count matches your schematic requirements. Ensure compatibility with the mating female connector within the SL 11 series. Check that the thermal profile of your soldering process aligns with the PA46 insulation limits.

Headers, Male Pins Selection Notes

Select this component when a low-profile, surface-mount male header is necessary for space-constrained designs. The 2.54 mm pitch ensures standard compatibility with existing mating hardware. Consider the push-pull feature if vibration resistance is critical. Verify that the 4-pin count meets the specific signal or power distribution needs of the application without requiring additional connectors.

Headers, Male Pins Part Context

This part belongs to the Fischer Elektronik SL 11 series, which offers various configurations including through-hole and surface mount options. The series is characterized by its modular design, allowing for different pin counts and row arrangements. The SL 11 164 4 S specifically addresses applications needing a compact, reliable surface-mount solution with high thermal stability.

Headers, Male Pins Replacement Considerations

Direct substitutes within the same family include other SL 11 series headers with matching pitch and locking style. Ensure any replacement maintains the 2.54 mm spacing and surface mount footprint. Verify that the insulation material and flammability rating meet the original specifications.
