SL 11 164 6 S

Headers, Male Pins Overview

The SL 11 164 6 S is a male pin header connector from Fischer Elektronik, designed for surface-mount technology (SMT) applications. It features a 2-row configuration with 6 positions and a standard 0.100 inch (2.54 mm) pitch. The contacts are gold-plated on the mating interface to ensure reliable signal transmission, while the posts are tin-plated for soldering stability. Constructed with copper-tin contacts and polyamide insulation, this component operates within a temperature range of -40°C to 163°C.

Headers, Male Pins Feature Summary

• Surface-mount design for automated PCB assembly
• Gold-plated mating contacts for corrosion resistance
• Polyamide insulation material for thermal stability

Headers, Male Pins Applications

• Consumer electronics board-to-board interconnects
• Industrial control system signal routing
• Telecommunications equipment internal connections

Headers, Male Pins Procurement Notes

Verify that the specific suffix 'S' denotes the surface-mount variant, as Fischer Elektronik uses distinct suffixes for through-hole and SMT versions. Confirm the contact finish matches the application requirements, as some variants may differ in plating thickness or material composition. Ensure the packaging quantity aligns with production needs, as these components are typically supplied in bulk reels or trays rather than individual units.

Headers, Male Pins Selection Notes

Select this component when a low-profile, surface-mount male header is required for high-density layouts. The 2.54 mm pitch ensures compatibility with standard ribbon cables and mating connectors. Consider the operating temperature range if the environment exceeds typical consumer electronics limits. Verify that the PCB footprint matches the specific SMT pad layout provided in the official datasheet to prevent soldering defects.

Headers, Male Pins Part Context

This part belongs to the SL 11 series, which offers various row counts and contact numbers. The SL 11 164 designation indicates a specific height and style within the Fischer Elektronik portfolio. Similar parts include the SL 11 164 6 G (through-hole) and other row configurations like the SL 11 124 series. The series is known for precision engineering and reliability in compact electronic assemblies.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 2.54 mm pitch, 6-position count, and surface-mount termination. Fischer Elektronik part SL 11 164 6 G is a through-hole equivalent but not a direct drop-in replacement due to mounting differences. No cross-brand substitutes are confirmed without verifying mechanical dimensions and electrical ratings against the original datasheet.
