SL 11 SMD 052 24 S SM

Headers, Male Pins Overview

The SL 11 SMD 052 24 S SM is a male header connector from Fischer Elektronik, designed for surface-mount technology (SMD) applications. It features 24 contacts constructed from CuSn-alloy, providing robust electrical connectivity. The component supports an AC voltage rating of 250 V with a test voltage of 2000 V. The insulating body is manufactured from PA material, ensuring stability in electronic assemblies.

Headers, Male Pins Feature Summary

• Surface-mount design for automated PCB assembly
• Male header configuration for reliable mating
• CuSn-alloy contact material for conductivity

Headers, Male Pins Applications

• Compact electronic device interconnections
• Surface-mount PCB assembly lines
• Signal and power routing in dense circuits

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix against the official Fischer Elektronik datasheet to confirm pin count, plating type, and tape/reel packaging specifications. Ensure the selected variant matches the required current and voltage ratings for the target application circuit.

Headers, Male Pins Selection Notes

Select this component based on the requirement for a 24-position SMD male header. Confirm compatibility with standard reflow soldering profiles and verify that the PA insulation class meets the thermal requirements of the assembly environment.

Headers, Male Pins Part Context

This part belongs to the SL 11 series of rectangular connectors by Fischer Elektronik. The series specializes in headers and plugs for printed circuit boards and ribbon cables, offering precision-engineered solutions for compact electronic connections.

Headers, Male Pins Replacement Considerations

Alternative options include other SL 11 series variants or comparable SMD male headers from different manufacturers. Verify mechanical dimensions, contact pitch, and mounting style before substitution.
