SL 11 SMD 130 28 S

Headers, Male Pins Overview

The SL 11 SMD 130 28 S is a male pin header connector manufactured by Fischer Elektronik. It features a surface mount design with 28 positions arranged in two rows. The contact pitch is 2.54 mm (0.100 inches). The connector supports board-to-board and wire-to-board applications. It is designed for straight mounting on printed circuit boards.

Headers, Male Pins Feature Summary

• Surface mount construction for automated pick-and-place assembly
• Dual row configuration providing 28 contact positions
• Standard 2.54 mm centerline spacing between pins

Headers, Male Pins Applications

• Board-to-board interconnection systems
• Wire-to-board connection interfaces
• General electronic equipment signal routing

Headers, Male Pins Procurement Notes

Verify the specific ordering suffix to confirm contact plating specifications and reel packaging quantities. Ensure the selected variant matches the required thermal resistance for soldering processes. Confirm that the housing material and terminal finish are compatible with the intended environmental operating conditions and regulatory compliance standards.

Headers, Male Pins Selection Notes

Select this component when a low-profile, dual-row male header is required for surface mount technology. The 2.54 mm pitch allows compatibility with standard ribbon cables and mating connectors. Consider the mechanical retention strength of the solder joints versus through-hole alternatives for vibration-prone environments.

Headers, Male Pins Part Context

This part belongs to the SL 11 series of PCB connectors from Fischer Elektronik. The series offers various contact counts and configurations. The SMD designation indicates surface mount capability. The model number encodes the specific pin count and row arrangement for precise identification within the product catalog.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 2.54 mm pitch, 2x14 contact layout, and surface mount footprint. Verify that alternative headers maintain identical housing dimensions and pin alignment tolerances to ensure proper mating with existing connectors.
