SL 12 SMD 083 15 S B SM

Headers, Male Pins Overview

The SL 12 SMD 083 15 S B SM is a surface-mount pin header from Fischer Elektronik. It features 15 positions in a single row with a 2.54 mm pitch. The connector utilizes gold-plated contacts for reliable signal transmission. The insulating body is constructed from PA 6.6 GF material, ensuring durability and stability. It supports a temperature range of -40°C to +163°C and meets UL 94 V-0 flammability standards.

Headers, Male Pins Feature Summary

• Surface-mount design for automated PCB assembly
• Gold-plated contacts for corrosion resistance
• High-temperature resistant PA 6.6 GF insulating body
• Single-row configuration with precise 2.54 mm spacing

Headers, Male Pins Applications

• General electronic circuit interconnections
• Industrial control system board-to-board connections
• Consumer electronics internal wiring
• Communication equipment signal routing

Headers, Male Pins Procurement Notes

Verify the exact part number against manufacturer datasheets to confirm contact plating thickness and specific packaging details. Ensure compatibility with standard SMD reflow profiles. Cross-reference insulation material specifications and thermal ratings with application requirements before finalizing procurement orders.

Headers, Male Pins Selection Notes

Select this component when surface-mount technology is required for high-density layouts. The 2.54 mm pitch ensures broad compatibility with standard connectors. Consider the operating temperature range and UL 94 V-0 rating for safety compliance. Verify mechanical retention needs and mating force requirements against the header's design specifications.

Headers, Male Pins Part Context

This component belongs to the SL 12 SMD series of pin headers by Fischer Elektronik. The series offers various pole counts and dimensions for flexible PCB integration. These headers are engineered for precision mounting and stable electrical performance in compact electronic assemblies requiring robust surface-mount solutions.

Headers, Male Pins Replacement Considerations

Direct substitutes must match the 15-position count, 2.54 mm pitch, and SMD footprint. Verify identical contact plating and insulating material properties. Check mechanical dimensions and height constraints to ensure fit within the target enclosure without interference.
