SL 16 SMD 157 66 Z

Headers, Male Pins Overview

The SL 16 SMD 157 66 Z is a surface mount male header connector manufactured by Fischer Elektronik. It features a 2-row configuration with 66 positions and a standard 0.100-inch (2.54 mm) pitch. The contacts are constructed from CuSn alloy with gold plating to ensure reliable conductivity. The insulator length can be customized according to specific customer requirements, allowing for flexible integration into various board-to-board or wire-to-board applications.

Headers, Male Pins Feature Summary

• Surface mount design for automated assembly processes
• Gold-plated CuSn alloy contacts for corrosion resistance
• Customizable insulator length based on application needs

Headers, Male Pins Applications

• Board-to-board interconnections
• Wire-to-board connections
• General electronic circuit assemblies

Headers, Male Pins Procurement Notes

Verify the exact contact count and row configuration against the datasheet before ordering. Confirm that the customizable insulator length meets your mechanical constraints. Ensure compatibility with standard surface mount reflow soldering profiles. Check for any specific handling instructions regarding the gold-plated contacts during storage and assembly.

Headers, Male Pins Selection Notes

Select this component when a high-density 2-row header is required for surface mount technology. The 2.54 mm pitch ensures compatibility with standard PCB footprints. Consider the customizable insulator feature if space constraints differ from standard dimensions. Verify that the gold plating meets the environmental durability requirements of the target application.

Headers, Male Pins Part Context

This part belongs to the SL 16 SMD 157 series of connectors from Fischer Elektronik. The series offers various position counts, including 16, 18, 32, and 66 positions. All variants share the same 2.54 mm pitch and surface mount mounting style, differing primarily in the number of contacts and potentially the insulator length.

Headers, Male Pins Replacement Considerations

Direct substitutes within the same series include SL 16 SMD 157 32 Z P and SL 16 SMD 157 18 Z P, provided the lower pin count is acceptable. Other variants like SL 16 SMD 207 66 S share the 66-position count but may differ in series specifications. Always verify mechanical dimensions and electrical ratings before cross-referencing.
